GE IC697MDL753C 32-Point DC Output Module
GE IC697MDL753C
Product Overview
The GE IC697MDL753C is a Series 90-70 discrete DC output module designed for industrial PLC applications. It provides 32 negative-logic output points arranged in two isolated groups of 16. The module supports 5 VDC TTL operation and 10–60 VDC field loads.
The “C” designation identifies a specific revision of the IC697MDL753 family. This makes revision matching important when replacing an existing module.
Technical Specifications
| Item | Specification |
|---|---|
| Manufacturer | GE Fanuc |
| Model | IC697MDL753C |
| PLC Family | Series 90-70 |
| Module Type | Discrete DC Output |
| Number of Outputs | 32 points |
| Output Groups | 2 isolated groups of 16 |
| Logic | Negative logic |
| Rated Voltage | 5 VDC or 10–60 VDC |
| Output Current | 0.5 A/point at 10–60 VDC |
| Group Current | 4 A maximum |
| TTL Operation | Supported |
| Output Type | DC transistor output |
The IC697MDL753 is documented as a 5/48 VDC, 0.5 A negative-logic, 32-point output module.
Main Features
- 32 high-density discrete outputs.
- Negative-logic output configuration.
- Two electrically isolated groups.
- Supports a wide DC voltage range.
- 0.5 A output capability per point at 10–60 VDC.
- LED indicators provide individual output status.
- TTL-level operation is supported.
- Designed specifically for GE Fanuc Series 90-70 PLC systems.
Output Architecture
The module divides its 32 outputs into two groups of 16. This arrangement provides electrical separation between the groups and can simplify load distribution within an industrial control cabinet.
Individual LED indicators allow technicians to monitor the ON/OFF status of the output points. The module is intended for loads such as motor starters, solenoids, and other compatible DC field devices.
Industrial Applications
The IC697MDL753C can be used where a Series 90-70 PLC needs a high-density DC output interface. Typical applications include:
- Factory automation
- Machine control
- Motor starter control
- Solenoid operation
- Industrial sequencing
- Distributed control panels
- Legacy PLC system maintenance
Its negative-logic architecture should be considered when designing or servicing the connected field circuit.
Installation & Maintenance
Before replacing the module, isolate the PLC system and associated field power. Confirm the module’s complete catalog number and revision before installation.
Check terminal wiring, load current, group loading, and field voltage. During troubleshooting, the individual LEDs can help identify output states.
For long-term storage, protect the module from static discharge, dust, moisture, and mechanical impact. When replacing an older IC697MDL753, matching the C revision can help maintain the intended system configuration.
————————————————————————————————————-
