Overview

Parameters

• Input Voltage Range: 180-250 VAC, supporting three-phase input.
• Communication Interfaces: Supports serial ports (e.g., RS-485), eight independent inputs and outputs, as well as DeviceNet programming and real-time diagnostic updates.
• Power Supply: 24V DC power supply, with a voltage fluctuation range of ±20% to adapt to industrial power grid fluctuations.
• Power Consumption: Typical power consumption of 2.6W, featuring a low-energy design.
• Operating Temperature: -20℃ to +85℃ (some models support 0℃ to +85℃).
• Input Voltage: 24V DC.
• Output Current: 0.5A per channel.
• Number of Channels: 8.
• Communication Protocol: EtherNet/IP.
• Operating Temperature Range: -20℃ ~ +60℃.

Product Features

• High Reliability: Adopts industrial-grade components and a high-reliability design to ensure stable operation.
• Modular Design: Facilitates installation and maintenance, and supports expansion and customization.
• Multiple Communication Interfaces: Supports a variety of communication interfaces, such as DeviceNet, CANopen, EtherNet/IP, Modbus, and Profibus, enabling easy integration with other devices.
• Overload Protection: Equipped with multiple protection functions including overcurrent, overvoltage, and overtemperature protection to ensure the safe operation of the device.
• High Performance: Utilizes advanced control algorithms and hardware to provide high-precision and high-response-speed control.
• User-Friendly Interface: Simplifies the setup and maintenance process, reduces downtime, and improves efficiency.
• Advanced Diagnostics: Integrates diagnostic tools to help solve problems and ensure minimal operational interruptions.

Structure and Composition

• Modular Design: The modular structure facilitates installation and maintenance, and supports expansion and customization.
• Hardware Structure: Adopts Surface Mount Technology (SMT). The top integrates components such as Ethernet ports, inductors, diodes, and resistors; the bottom mainly consists of capacitors and resistors to optimize space utilization.
• Installation Method: Fixed to a larger circuit board through screw mounting bases to ensure mechanical stability.
• Protection Level: Features an aluminum alloy housing that is wear-resistant, corrosion-resistant, and resistant to electromagnetic interference (with EMC certification).

Application Fields

• Industrial Automation: Used for data acquisition and control in various industrial automation systems.
• Process Control: Used to monitor process parameters and execute corresponding control actions.
• Machine Automation: Used to control the joint movement of robots, the feed movement and tool movement of machine tools, and the movement of packaging machinery.
• Manufacturing Industry: Applied in CNC machine tools, robots, automated production lines, etc.
• Energy and Chemical Industry: Used for the precise control of equipment such as pumps, fans, and compressors.
• Packaging Machinery: Used for motion control of packaging machinery.
• Printing Machinery: Used for precise motion control of printing machinery.
• Aerospace and Medical Equipment: Suitable for special industries that require high-precision motion control.

Installation and Maintenance

• Installation Steps: Prepare tools and materials, select an appropriate installation location, fix the base bracket and ground it, connect the power supply and signal lines, and ensure firm connections and good insulation.
• Configuration: Perform basic configuration through the DIP switches on the front panel of the module or the software interface, and set communication parameters, input/output types, protection thresholds, etc.
• Maintenance: The modular design facilitates installation and maintenance; the system can be quickly restored to operation by replacing key components.
