GE IS200EISBH1A Exciter ISBus Board

Short Description:

The GE IS200EISBH1A is an Exciter ISBus Board, which serves as a core component of the GE EX2100 excitation control system.

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: GE

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-18250705533

( WhatsApp )Wechat: + 86-18250705533

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

GE IS200EISBH1A

1. Product Overview

The GE IS200EISBH1A is an Exciter ISBus Board, which serves as a core component of the GE EX2100 excitation control system. As a member of the GE Mark VI series, it is specially designed for data communication among M1, M2 and C controllers. As a dedicated communication interface board, it receives optical fiber feedback signals through the control backplane and transmits them to the DSPX controller. Manufactured by General Electric Industrial Systems, this product is made in the United States.

2. Technical Parameters

Parameter Item	Value / Specification
Dimension	230mm × 170mm × 85mm / 19×13×3cm
Weight	0.2kg-0.8kg / 2kg
Height	3U height module
Slot Quantity	Single-slot design
Power Supply Voltage	24V DC
Input Voltage Range	0-700V AC (±0.1% accuracy)
Current Range	0-700A AC (±0.2% accuracy)
Operating Temperature	-30℃ to 65℃
Channel Quantity	12 channels
Digital I/O	16 input channels and 16 output channels respectively
Communication Interface	RS-232C, Ethernet, RS-485, optical fiber connector
Data Rate	1200 to 38.4 KBaud

3. Product Features

High Reliability: Adopts industrial-grade components and professional diagnostic functions to ensure stable operation and anti-damage performance of the product.
Redundant Design: Equipped with ISBus interface electronics for redundant exciters, effectively improving the overall reliability and stability of the control system.
Modular Structure: Features a single-slot and 3U-height modular design, which greatly facilitates on-site installation and daily maintenance work.
Multi-interface Communication: Realizes data communication between DSPX, tools and keyboard ports via backplane connectors through RS-232C interface.
Powerful Signal Processing Capability: Converts current and voltage analog signals of the exciter into digital signals, and transmits the processed signals to DSPX or other controllers via optical fiber connectors for real-time processing and monitoring.
Easy Maintenance: The optimized modular structure and matched image analysis tools simplify the fault inspection and maintenance process.

4. Structure and Composition

4.1 Physical Structure

Adopts single-slot and 3U-height modular form
Installed in the control rack below the DSPX module

4.2 Main Components

Optical Fiber Connector: The front panel is equipped with two sets of optical receiving sockets to collect current and voltage signals of the generator magnetic field.
Backplane Connector: Responsible for the transmission and reception of optical fiber signals between modules.
EGDM Interface: Realizes signal receiving and transmission with the Earth Ground Detection Module (EGDM).
Reset Switch: A dedicated reset switch is integrated on the board for system reset operation.
RS-232C Driver: Supports stable and efficient serial data transmission.

4.3 Internal Electronic Components

Relays and transistors
2 transformers
More than 20 integrated circuits
Various resistors and capacitors

5. Application Fields

This module is widely used in industrial automatic control scenarios requiring high-precision excitation control and system stability monitoring, with specific application fields as follows:

Power Generation System: Excitation control and stability regulation of large-scale generator sets
Turbine Management: Automatic management and precise control of gas turbines and steam turbines (compatible with GE Mark VI series systems)
Oil and Gas Industry: Industrial process automatic control
Papermaking Industry: Automatic control of pulping and papermaking production lines
Mining Industry: Intelligent automation and equipment control for mining operations
Water Treatment Industry: Automatic operation control of water treatment facilities
Manufacturing Industry: Factory automated production and robot system control
HVAC and Motor Control: Heating, ventilation and air conditioning system control, as well as motor operation regulation

6. Installation and Maintenance

6.1 Installation Precautions

Anti-static Protection: The board is an electrostatic-sensitive component. Direct contact with the circuit board is prohibited, and anti-static gloves must be worn during operation.
Storage Environment: It is recommended to store the module in a professional anti-static box and comply with standard storage conditions. Improper storage and handling will affect the product performance and service life.
Installation Position: The module shall be installed in the specified position of the control rack below DSPX, matching the 3U-height and single-slot specification.
Connection Requirements: Ensure accurate and firm connection of optical fiber connectors, backplane connectors and EGDM interfaces to avoid signal failure.

6.2 Maintenance Key Points

Regular Inspection: Regularly check the system operating status and working environment to ensure long-term stable operation of the module.
Fault Diagnosis and Repair: Support rapid fault detection and targeted repair, with emergency maintenance services available.
Professional Maintenance: All maintenance work is completed by professional technicians with dedicated tools in a standardized controlled environment. All replacement parts are industrial-grade and fully compliant with OEM standards.
Refurbishment Service: Provide professional module refurbishment services, including aging component replacement, TIL modification, reflow soldering, deep cleaning and protective coating treatment.
