GE SGLA36AI0400 Circuit Breaker
GE SGLA36AI0400
1. Overview
GE SGLA36AI0400 is a 3-pole (3P) Mag-Break Circuit Breaker, usually used in medium and low voltage power distribution systems. It belongs to the Mag-Break type (SGLA) of the GE Spectra RMS series, which is famous for its high reliability and powerful current limiting function.
______________________________________________________________________________________________
2. Core Parameters
|
Parameter
|
Specification
|
|---|---|
|
Model
|
GE SGLA36AI0400
|
|
Rated Current
|
400A
|
|
Pole Number
|
3 Pole (3P)
|
|
Rated Voltage
|
600V (usually 600 VAC)
|
|
Rated Breaking Capacity
|
65kA @ 480V (some data shows 100kA @ 480V)
|
|
Limit Current
|
250A (mentioned in some documents)
|
|
Rated Plug
|
400A Plug
|
|
Rated Short-Circuit Current
|
150kA (inferred from series specifications)
|
______________________________________________________________________________________________
3. Product Features
- Current Limiting Function: Through magnetic break technology, when a short-circuit fault occurs, it can limit the fault current to around the limit current (usually 250A), preventing excessive fault current from burning out equipment.
- High Reliability: The Spectra RMS series is GE’s core product, with excellent switching performance and service life.
- Modular Design: Adopts plug-in installation, which is convenient for quick replacement and maintenance.
______________________________________________________________________________________________
4. Structure and Composition
- Magnetic Trip Coil: Responsible for quickly cutting off the circuit in case of high-current faults.
- Thermal Magnetic Mechanism: Provides overload protection (thermal) and short-circuit protection (magnetic).
- Contacts System: Responsible for actual on-off operations.
- Frame: Provides mechanical support and installation interface.
______________________________________________________________________________________________
5. Application Fields
- Distribution Transformer Outlet: Used as a protection device for the main power supply.
- Industrial Motor Control: Protects high-power motors from short-circuit and overload damage.
- Power Distribution Cabinet: Used for incoming line protection in large power distribution cabinets or distribution boxes.
- Power Stations and Power Plants: Serves as a key protection component of the electrical system.
______________________________________________________________________________________________
6. Installation and Maintenance
Installation
- Wiring: Wire according to the wiring diagram in the product manual to ensure firm wiring and reliable insulation.
- Grounding: The frame should be reliably grounded to ensure safety.
Commissioning
- Closing: Before turning on the power, close the breaker first to ensure mechanical locking.
- Opening: Before maintenance or component replacement, open the breaker to cut off the power supply.
Maintenance
- Regular Inspection: Check the wear of the contacts and replace them if necessary.
- Cleaning: Keep the breaker shell and internal vents clean to prevent overheating caused by dust accumulation.
- Function Test: Conduct regular mechanical operation tests and electrical characteristic tests.
————————————————————————————————————-
