Bently Nevada 3500-50M PWA 286566-02P Speed Measurement Module
BENTLY NEVADA 3500-50M PWA 286566-02P
1. Overview
Bently Nevada 3500-50M PWA 286566-02P is a tachometer module specifically designed for high-speed rotating equipment, belonging to the Bently Nevada 3500 series mechanical protection system. This module is mainly used to collect the speed, rotor acceleration or direction of rotation signals of rotating machinery, and is widely applied in heavy industry fields such as electric power, petrochemical, papermaking, iron and steel, and coal to realize continuous online monitoring and status evaluation of key equipment.
______________________________________________________________________________________________
2. Core Parameters
- Input Channels: 2 channels, supporting Proximity Probe or Magnetic Pickup input.
- Measurement Range: 0 to 20,000 RPM (the maximum upper limit is not clearly specified in some documents, but it usually covers the industrial range up to 20,000 RPM).
- Accuracy and Resolution: Accuracy ±0.01% FS, Resolution 0.01 RPM.
- Power Requirement: 12-30V DC.
- Operating Environment: -40°C to +85°C (Storage Temperature: -55°C to +90°C).
- Output Signals: 4-20mA, 0-10V, supporting key phase signal output.
- Communication Interface: Supports Ethernet and RS-485.
- Protection Level: IP65, suitable for harsh industrial environments.
______________________________________________________________________________________________
3. Structure and Composition
- Module Body: Core electronic circuit board, responsible for signal collection and processing.
- Internal Terminals: Equipped with standard terminals for easy connection of sensor cables.
- Peak Hold Function: Integrates a built-in Peak Hold function, which can store the maximum speed and be manually reset by the user.
______________________________________________________________________________________________
4. Application Fields
- Generator Sets: Monitoring the rotor speed and synchronization status of generators.
- Petrochemical Pumps: Monitoring the operating speed of pumps to prevent bearing damage caused by overspeed operation.
- Wind Turbines: Monitoring the speed of wind turbine blades.
- Machine Tool Spindles: Monitoring the precise speed of high-speed spindles.
______________________________________________________________________________________________
5. Installation and Maintenance
Installation
Insert it through the dedicated slot on the rack backplane to ensure connection with the backplane and power bus of the 3500 system. It is recommended that wiring and commissioning be performed by professional engineers.
Maintenance
The module is designed with a sealed structure (IP65), which has strong resistance to environmental dust and moisture and usually does not require frequent cleaning. It is recommended to regularly check the connection status of sensor cables and the power supply voltage of the module to prevent inaccurate measurement or signal loss caused by external environmental impacts.
————————————————————————————————————-
