1. Overview

2. Parameters

• Voltage Level: Usually 10kV (35kV or other specifications may also be available).
• Rated Current: The rated load current is usually 0.5A or 1A (depending on the voltage level and specific requirements).
• Accuracy Class: Generally meets 0.2, 0.5 or 1.0 class accuracy (specifically according to the application scenario).
• Protection Class: IP54 or IP65, suitable for industrial environments.
• Temperature Class: Usually Class F (105℃) or Class H (180℃).
• Installation Method: Optional oil-immersed or dry-type structure; oil-immersed type usually has better heat dissipation performance.

______________________________________________________________________________________________________

3. Product Features

• High Accuracy: Adopts GE’s advanced manufacturing technology to ensure minimal voltage measurement error.
• Compact Structure: Compared with traditional transformers, the TGN3324R adopts a compact design, saving installation space.
• Long Service Life: Uses high-quality insulating materials and oil (if oil-immersed), ensuring a long service life.
• High Safety: Equipped with overload protection and good insulation performance, which can effectively prevent electrical accidents.
• Strong Adaptability: Can adapt to various harsh environments and has strong anti-interference ability.

______________________________________________________________________________________________________

4. Structure and Composition

• Core: Usually made of laminated silicon steel sheets to provide a magnetic flux channel.
• Primary Winding: Connected to the high-voltage power grid with fewer turns.
• Secondary Winding: Outputs standard low-voltage signals with more turns.
• Tank: If oil-immersed, it is filled with insulating oil for heat dissipation and insulation.
• High-Voltage Bushing: Connects the primary winding to the external power grid.
• Bracket and Base: Provide structural support to ensure the transformer is stable.

______________________________________________________________________________________________________

5. Application Fields

• Power Plants: Used for voltage monitoring of generators.
• Substations: Used for voltage measurement of transformers, capacitor banks and switchgear.
• Distribution Networks: Used for voltage monitoring of distribution transformers and distribution lines.
• Industrial Enterprises: Used for high-voltage power monitoring in large factories and enterprises.

______________________________________________________________________________________________________

6. Installation and Maintenance

Installation

• Base Fixing: During installation, the transformer must first be fixed on a solid base to ensure levelness.
• Wiring: Connect the primary high-voltage cable and the secondary low-voltage cable, ensuring strict insulation separation between the primary and secondary sides.
• Grounding: Effective grounding must be carried out to prevent hazards caused by electromagnetic induction.

Maintenance

• Oil-Immersed Maintenance: Regularly check the oil level and oil quality, conduct oil sample analysis, and detect impurities and moisture in the oil.
• Dry-Type Maintenance: Regularly check the insulation performance to ensure no dust accumulation.
• Regular Inspection: Regularly conduct electrical tests (such as DC resistance test, dielectric loss test) and temperature detection of the transformer to prevent faults.
