GE TPSS6620 Protection Device
GE TPSS6620
1. Overview
GE TPSS6620 is a product of the TPSS (Trip Protection System) series developed by GE (General Electric) Company. It is usually integrated into larger power system protection suites (such as the TPSS 6280 series) to monitor current and voltage signals, and issue a trip command to cut off the faulty circuit when an abnormality is detected.
______________________________________________________________________________________________
2. Specifications
|
Specification
|
Description
|
|---|---|
|
Rated Current
|
2000 A
|
|
Rated Voltage
|
600 V
|
|
Poles
|
3 POLE
|
|
Function Type
|
Circuit Breaker
|
|
Trigger Mode
|
Manually, i.e., trip is triggered by manual operation or relay control
|
|
Status Indication
|
Gray label, usually used to distinguish different electrical functions or safety levels
|
______________________________________________________________________________________________
3. Product Features
- High-Speed Response: Adopting microcomputer control, it can complete fault detection and trip operation within milliseconds.
- Multi-Pole Design: Supports 3-pole configuration, suitable for the protection of three-phase circuits.
- High Current Capacity: With a rated current of up to 2000A, it is suitable for high-power industrial circuits.
- Manual Control: Trip commands can be issued through manual buttons or other control systems (such as PLC).
______________________________________________________________________________________________
4. Structure and Composition
- Control Unit: A microprocessor-controlled circuit responsible for monitoring signals and executing trip logic.
- Relay Contacts: High-voltage contacts used to connect external circuits.
- Power Supply: Provides DC voltage required for internal circuits.
- Terminal Blocks: Used to connect input current/voltage sensors and output control lines.
______________________________________________________________________________________________
5. Application Fields
- Industrial Automation: Used for overload protection of large industrial motors and equipment.
- Power Systems: Used for line protection in substations or power distribution rooms.
- Infrastructure: Places requiring high-reliability power protection, such as hydropower stations and mines.
______________________________________________________________________________________________
6. Installation and Maintenance
Installation
- Location: It should be installed in a dry and well-ventilated environment, avoiding direct sunlight and high temperature.
- Wiring: Strictly follow the wiring diagram provided by GE to ensure correct connection of current/voltage sensors and control lines.
Maintenance
- Regular Inspection: Regularly check the tightness of terminal blocks and the wear of contacts.
- Function Test: Conduct a function test at least once a year to ensure it can trip normally in case of faults.
- Cleaning: Keep the surface clean to avoid overheating caused by dust accumulation.
————————————————————————————————————-
