HIMA F3 DIO 8/8 01 Remote I/O Module
HIMA F3 DIO 8/8 01
1. Overview
HIMA F3 DIO 8/8 01 is a compact metal-enclosed remote I/O module within the HIMatrix F3 series of safety controllers. Specifically designed for HIMA safety systems, it features safety-related digital input/output functions and enables reliable data interaction with upper-level controllers via a safety network.
2. Main Specifications
| Specification | Description |
|---|---|
| Model | F3 DIO 8/8 01 (also commonly written as F3 DIO 8/8 01) |
| Enclosure | Metal housing, compatible with standard DIN rails |
| Input | 8 channels of digital input (DI) |
| Output | 8 channels of digital output (DO+, L grounding)
2 channels of digital output (DO‑, S grounding) 2 channels of pulse output |
| Bipolar Output Connection | Some outputs can be connected in bipolar mode: DO4+, DO8+, DO4‑, DO8‑ can be used as two poles (+ / –) |
| Power Supply | 24 V DC (safety power supply) |
| Communication | Secure data transmission via HIMA safety networks (such as PROFIsafe, Ethernet/IP Safety) |
| Operating Temperature | -25 °C ~ +55 °C (refer to the product manual for specific details) |
| Protection Class | IP20 (for indoor installation) |
3. Product Features
- Safety and Reliability: Equipped with safety-related digital I/O. Input values are securely transmitted through the safety network, and output values are also controlled by the safety network.
- Compact Metal Structure: The metal enclosure provides excellent anti-interference performance and mechanical strength, making it suitable for harsh industrial on-site environments.
- Multifunctional Output: In addition to 8 channels of standard digital output, it also offers 2 channels of DO‑ (S grounding) and 2 channels of pulse output, meeting the control requirements of various safety valves and actuators.
- Bipolar Output Option: Some digital outputs (DO4+/DO8+, DO4‑/DO8‑) can be configured for bipolar connection, enhancing wiring flexibility.
- Strong Compatibility: Can be directly integrated into HIMA F3 series or other compatible safety controllers, supporting multiple safety network protocols.
4. Structure and Composition
- Metal Enclosure: Provides mechanical protection and electromagnetic shielding.
- Input Terminal Block: 8-channel DI terminals, using screw-type or spring-type wiring.
- Output Terminal Block: Includes 8 channels of DO+ (L grounding), 2 channels of DO‑ (S grounding), and 2 channels of pulse output terminals.
- Power Supply Module: Built-in 24 V DC safety power supply with overvoltage/undervoltage protection.
- Communication Interface: Dedicated ports for connecting to safety networks (e.g., PROFIsafe, Ethernet/IP Safety).
- Indicator Lights: Status indicators show power supply, communication, and fault statuses.
5. Application Fields
- Petrochemical Industry: Safety Instrumented Systems (SIS) for oil refining and chemical plants.
- Offshore Platforms: Safety control for offshore oil platforms.
- Long-Distance Pipelines: Safety monitoring of pipeline leaks and valves.
- Gas Stations: Safety instrumentation and protection systems for gas stations.
- Other High-Risk Industries: Scenarios requiring safety monitoring, such as power generation, metallurgy, and pharmaceutical manufacturing.
6. Installation and Maintenance
Installation
- Fix the module on a standard DIN rail to ensure the metal enclosure is securely fastened.
- Connect the 24 V DC power supply, digital inputs, digital outputs, and safety network communication lines according to the wiring diagram.
- Check that all terminals are in good contact to avoid loosening.
————————————————————————————————————-
