HIMA F8650X Safety Central Module
HIMA F8650X
The HIMA F8650X is a high-performance safety central module developed by HIMA Germany, widely applied in industrial automation systems. Serving as the core processing unit of the Safety Instrumented System (SIS), it is responsible for executing safety logic, processing input and output signals, and conducting fault diagnosis, providing reliable safety protection for various industrial critical processes.
____________________________________________________________________________________________
1. Product Overview
Core Positioning: The HIMA F8650X is a key product of HIMA’s Safety Instrumented System (SIS) series, specially designed for integration with H51q-MS, HS and HRS systems, acting as the core control component of the entire safety system.
Primary Function: As a central module for safety-critical applications, it delivers stable and reliable safety control functions for industrial processes. It features rapid emergency response capabilities to trigger protective measures in a timely manner, effectively preventing safety accidents and minimizing operational risks.
____________________________________________________________________________________________
2. Technical Specifications & Parameters
|
Parameter Category
|
Specific Parameters
|
Remarks
|
|---|---|---|
|
Processor
|
Intel 386EX (32-bit) / PowerPC 604e
|
Equipped with powerful computing capacity, supporting real-time industrial control
|
|
Clock Frequency
|
25 MHz
|
Meets the high-speed response requirements of industrial automation scenarios
|
|
Memory & Storage
|
1 MB Flash-EPROM (OS); 1 MB Flash-EPROM (user program); 1 MB SRAM (data)
|
Ensures stable and reliable execution of complex safety logic algorithms
|
|
Power Supply Requirements
|
Input: 24V DC; Output: 5V/2A
|
Complies with international industrial power supply standards, strong compatibility
|
|
Operating Temperature
|
-40°C to +85°C
|
Adapt to harsh industrial working environments with extreme temperature changes
|
|
Protection Grade
|
IP20 / IP30
|
Professional dust and splash protection, suitable for industrial workshop control cabinets
|
|
Safety Rating
|
SIL 3 / SIL 4 (Compliant with IEC 61508)
|
High safety integrity level, meets the strictest safety standards of industrial fields
|
|
Communication Interfaces
|
2 x electrically isolated RS485; 1 x PROFIBUS; 1 x CAN; 1 x USB; 1 x Ethernet
|
Supports multiple mainstream industrial network protocols, easy system integration and data interaction
|
____________________________________________________________________________________________
3. Key Product Features
3.1 Dual Microprocessor Redundant Design
The F8650X adopts a redundant configuration of dual microprocessors, which can automatically switch to the backup processor in the event of a single processor fault without manual intervention. This design maximizes the system’s availability and operational reliability, and ensures the continuous and stable operation of industrial safety control.
3.2 Industry-Leading Safety Performance
Fully compliant with the IEC 61508 international safety standard, it is a core safety component with SIL 3 and even SIL 4 ratings. It supports core safety functions such as emergency shutdown (ESD) and safety interlock, forming a solid safety barrier for critical industrial processes.
3.3 Rich & Versatile Communication Capabilities
Integrated with a full set of industrial communication interfaces including PROFIBUS, Ethernet and CAN, it realizes seamless data exchange and interconnection with various industrial equipment, DCS systems and upper monitoring platforms. The electrically isolated RS485 interface further improves the anti-interference ability of communication and ensures the accuracy of data transmission.
3.4 Real-Time Diagnosis & Intuitive Status Display
Built-in safety watchdog circuit, multi-group LED status indicators and 4-digit nixie tube display, which can monitor the running status of the module in real time. Once a fault occurs, it can quickly output accurate fault diagnosis information, helping maintenance personnel locate and solve problems efficiently and reduce equipment downtime.
____________________________________________________________________________________________
4. Product Structure & Components
The HIMA F8650X adopts a highly integrated modular design, with clear functional division and stable structural performance, which is convenient for installation, debugging and maintenance:
- CPU Core: Dual-core microprocessor (Intel 386EX / PowerPC 604e), the core computing unit of the module, responsible for the operation of safety logic and real-time processing of industrial process data.
- Storage Unit: Classified storage of Flash-EPROM (OS and user program) and SRAM (real-time data), ensuring data security and fast reading/writing speed.
- Communication Module: Integrated professional industrial communication interface circuit, supporting multi-protocol data transmission and realizing seamless connection with the industrial control network.
- Power Supply Module: High-efficiency power conversion unit, which stably converts external 24V DC power into 5V/2A working power required by the internal circuit, with overvoltage and overcurrent protection functions.
- Human-Machine Interface (HMI): Combined with nixie tube and LED indicator, it provides intuitive visual feedback of module running status (power on, normal operation, fault, communication, etc.), and is easy for on-site operation and monitoring.
____________________________________________________________________________________________
5. Application Fields
With its high safety, reliability and compatibility, the HIMA F8650X is widely used in various safety-critical industrial fields, and is the first choice for building high-performance SIS systems:
- Process Industry: Hazardous process control in petroleum, natural gas, chemical industry, metallurgy and other industries, such as reactor safety control, pipeline transportation protection, and chemical production process interlock.
- Energy System: Power generation unit control, burner safety management, steam turbine and gas turbine operation protection, new energy power station safety control.
- Transportation & Construction: Safety monitoring and interlock control of transportation systems (rail transit, port machinery), safety protection of building automation systems and large-scale industrial building equipment.
____________________________________________________________________________________________
6. Installation & Maintenance
6.1 Easy Installation
Adopting the international standard DIN-rail mount design, it can be quickly fixed and installed in industrial control cabinets, with a compact structure that saves installation space. The standardized interface and wiring mode reduce the difficulty of on-site installation and debugging, and improve the construction efficiency.
6.2 Convenient & Efficient Maintenance
- Supports hot-swap and redundant configuration technology, allowing the module to be replaced and maintained without interrupting the normal operation of the entire safety system, realizing non-stop maintenance of industrial production.
- The built-in intelligent fault diagnosis function can real-timely monitor the module status, record fault information and historical operation data, which is convenient for maintenance personnel to conduct predictive maintenance and fault analysis.
- The modular structural design makes the replacement of spare parts simple and fast, effectively shortens the equipment maintenance time and reduces the maintenance cost of the enterprise.
————————————————————————————————————-
If you would like to learn more about our products and services, please feel free to contact us at any time!
- Sales Manager : Jinny
- Email : sales5@xrjdcs.com
- Whatsapp/Mobile:+86 15359273791
