HIMA F8652X Control System Module
HIMA F8652X
1. Overview & Core Functions
The HIMA F8652X is a high-performance industrial safety control module engineered to deliver robust safety logic processing and fault management for critical industrial systems. Its core functions are designed to ensure operational safety and regulatory compliance in high-risk scenarios:
- Safety Logic Operation: Executes complex safety algorithms and logical operations, enabling the system to switch to a safe state rapidly in the event of a fault.
- Real-time Fault Diagnosis: Monitors the module’s internal status in real time, with accurate detection of hardware and software malfunctions for timely troubleshooting.
- Compliant Data Logging: Automatically records safety events, alarm logs and operational records, fully meeting the data retention and traceability requirements of industrial regulatory standards.
____________________________________________________________________________________________
2. Technical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Model
|
F8652X
|
|
Processor
|
Dual-core processor (specific model may vary by batch, e.g., 6ES7 315-2AG14-0AB0)
|
|
Memory
|
256 KB – 512 KB SRAM; 512 KB – 1 MB Flash-EPROM
|
|
I/O Interface
|
Digital I/O: 8-16 points (configurable); Analog I/O: Supported on selected models
|
|
Communication Interfaces
|
PROFIBUS DP, 2×RS485 serial ports; Ethernet/IP supported on selected models
|
|
Power Supply
|
24V DC input, low power consumption (compliant with industrial energy efficiency standards)
|
|
Safety Rating
|
IEC 61508 SIL 3 / PLe certified
|
|
Operating Temperature
|
-20°C to +60°C
|
|
Protection Class
|
IP20 (for indoor cabinet installation)
|
|
Mechanical Design
|
DIN rail mountable module; Approx. dimensions: 100mm × 50mm × 30mm
|
3. Key Features
3.1 Industry-leading Safety Performance
Certified to IEC 61508 SIL 3 and PLe international safety standards, the module features a redundant design that prevents single-point faults from causing system failure, ensuring uninterrupted safety control for critical processes.
3.2 Compact Modular Design
With a space-saving structure and standard DIN rail mounting, the F8652X integrates seamlessly into existing industrial control cabinets, reducing installation space and simplifying system layout for industrial sites.
3.3 Multi-protocol Communication Compatibility
Native support for PROFIBUS DP and optional Ethernet/IP enables smooth integration with upper-level SCADA systems, DCS master stations and PLC controllers, realizing seamless data exchange and remote control in industrial networks.
3.4 User-friendly Programming
Supports mainstream industrial programming languages including Ladder Diagram (LAD) and Function Block Diagram (FBD). The intuitive programming logic shortens the learning curve for engineers and accelerates project commissioning and debugging.
____________________________________________________________________________________________
4. Module Structure & Components
The HIMA F8652X adopts an integrated modular design, with all core components optimized for safety and stability, ensuring reliable operation in harsh industrial environments:
- CPU Module: The core processing unit, responsible for executing all safety logic algorithms and real-time system control.
- I/O Module: Provides configurable digital and analog I/O channels (built-in on selected models) for signal collection and actuator control.
- Communication Interface: Equipped with PROFIBUS DP and RS485 ports (Ethernet/IP optional) for stable data transmission with industrial control equipment.
- Status Indicator & Display: Visual LED indicators for real-time monitoring of operating status, fault codes and communication links, enabling quick fault location.
____________________________________________________________________________________________
5. Typical Application Fields
Engineered for high-risk and critical industrial processes, the HIMA F8652X is widely used in industries with strict safety requirements:
- Petrochemical & Chemical: Leakage alarm systems, explosion protection control, critical valve interlock control for storage and transportation systems
- Metallurgy & Steel: High-temperature furnace safety control, molten salt tank monitoring and thermal process interlock
- Nuclear Power: Redundant control of key safety systems, reactor auxiliary equipment safety interlock
- Rail Transit: Train braking system control, platform door interlock and track safety monitoring
- Paper & Packaging: Safety interlock for high-speed production lines, equipment emergency stop control
____________________________________________________________________________________________
6. Installation & Maintenance Guidelines
6.1 Professional Installation Requirements
- Adopt standard DIN rail mounting; ensure the power supply is disconnected before installation to avoid electrical hazards.
- Mount the module horizontally in the control cabinet and fasten all fixing screws to prevent vibration-induced loosening.
- Reserve sufficient ventilation space around the module to ensure heat dissipation and avoid high-temperature accumulation.
6.2 Wiring & Configuration
- Connect the power supply, I/O signals and communication linesstrictly in accordance with the official wiring diagram; distinguish between analog and digital signal lines to prevent interference.
- Confirm the electrical characteristics of input signals (current loop, voltage loop or resistance loop) before wiring to ensure signal matching.
- Complete I/O assignment and safety logic programming via HIMA’s dedicated programming software, then download the program to the module and conduct on-site commissioning and functional testing.
6.3 Routine Maintenance
- Regularly inspect the module’s ventilation and heat dissipation conditions to avoid overheating caused by dust accumulation.
- Check I/O terminals and wiring connections for loosening, corrosion or oxidation; tighten and clean in a timely manner.
- Perform functional self-tests in accordance with the official user manual at regular intervals to verify the normal operation of safety logic and fault alarm functions.
- Keep the module’s operating environment clean and dry; avoid exposure to corrosive gases, excessive humidity and strong electromagnetic interference
————————————————————————————————————-
