HIMA P8403 Digital Input Module
HIMA P8403
1. Overview
HIMA P8403 is a module designed for collecting and transmitting digital signals (such as switch signals and pulse signals). It is mainly applied in the field of industrial automation. By collecting the switch status or counting signals of on-site equipment, it transmits them to PLCs or safety controllers for processing and control.
_____________________________________________________________________________________________________________
2. Specifications
Dimensions & Weight
- Dimensions: 152 mm x 114 mm x 66 mm (W x H x D) or 257 mm x 114 mm x 97 mm (specific dimensions depend on the specific model configuration).
- Weight: Approximately 700 grams to 1200 grams.
Electrical Specifications
- Power Supply: 24 VDC, allowing a deviation of -15% to +20%, supporting SELV/PELV safety power supply standards.
- Power Consumption: Idle power is approximately 12 W, and the maximum power can reach 216 W.
- Operating Temperature: 0…60 °C; Storage Temperature: -40 °C…+85 °C.
Communication & Interfaces
- Compatible with PROFIsafe bus interfaces (such as SK CU4-PNS and SK TU4-PNS).
- Provides Ethernet/IP communication capability (for some models).
_____________________________________________________________________________________________________________
3. Product Features
- Multifunctional Collection: Supports 16 digital input ports (no electrical isolation) and 4 pulse outputs for line monitoring.
- Modular Design: Rectangular structure, easy to integrate with other modules, suitable for DIN rail mounting.
- Safety: Complies with IEC 61131-2 safety standards and supports safety isolated power supply units.
- Strong Compatibility: Applicable to Plantguard series PLC systems and HIMA Matrix safety systems.
_____________________________________________________________________________________________________________
4. Structure & Composition
- Modular Chassis: Usually made of metal or plastic, equipped with indicator lights and terminal blocks.
- Input/Output Terminals: Provide digital input terminals, pulse counting input terminals and Ethernet ports (if any).
- Communication Interface: Integrates PROFIsafe communication module to support bus communication.
_____________________________________________________________________________________________________________
5. Application Fields
- Industrial Automation: Used for digital quantity collection of PLC systems to monitor equipment switch status and counting signals.
- Safety Systems: As an input module of safety control systems, it collects signals from safety switches, emergency stop buttons, etc.
- Process Control: Used for signal collection of external equipment such as flow meters and sensors.
_____________________________________________________________________________________________________________
6. Installation & Maintenance
Installation Method
Install horizontally on a 35 mm DIN rail. A horizontal distance of at least 20 mm and a vertical distance of at least 100 mm are required to ensure ventilation.
Maintenance Points
Regularly check the power supply and communication connections to ensure that the ambient temperature is within the operating range. Avoid excessive humidity or dust affecting the module performance.
————————————————————————————————————-
