HIMA PS-1000-WR-011 Monitoring Module
HIMA PS-1000-WR-011
1. Product Overview
- Positioning: The HIMA PS-1000-WR-011 is a pressure sensing/monitoring module with high reliability, complying with safety standards such as SIL 3 / PL e.
- Core Functions: It measures process pressure in real time and outputs safety signals, which can be directly connected to HIMA safety controllers or other PLC systems.
- Applicable Standards: It meets functional safety standards including IEC 61508, IEC 61511, and EN 50128, and is equipped with explosion-proof protection (IP 20 / Ex-d).
2. Key Technical Parameters
- Measurement Range: 0 ~ 1000 bar (optional). Different range requirements can be achieved by replacing the range module.
- Accuracy: ±0.2 % FS, which meets the requirements of high-precision process control.
- Output Signals: 4-20 mA (analog); PROFIBUS/PROFINET (digital). It supports dual channels of analog and fieldbus.
- Power Supply: 24 V DC, conforming to industrial power supply standards.
- Protection Level: IP 20, Ex-d (explosion-proof), suitable for hazardous areas.
- Operating Temperature: –25 °C ~ +85 °C. The wide temperature range ensures reliability.
- Response Time: ≤10 ms. Fast response meets the needs of safety interlock.
3. Product Features
- High Safety: Built-in self-test function, supporting dual-channel redundancy, and meeting SIL 3 / PL e certification.
- Modular Structure: Adopting DIN rail mounting, which facilitates on-site arrangement and later expansion.
- Multi-Protocol Compatibility: Compatible with industrial buses such as Modbus RTU, PROFIBUS, and PROFINET, enabling easy integration.
- Fanless Design: Fully enclosed heat dissipation, reducing maintenance costs and improving protection level.
- Easy Maintenance: Provides complete online diagnosis and fault recording functions, and supports remote monitoring.
4. Structure and Composition
- Housing: Metal protective housing, meeting Ex-d explosion-proof requirements.
- Sensing Unit: High-precision piezoresistive or piezoelectric pressure sensor (optional).
- Signal Processing Board: Built-in A/D conversion, calibration algorithm, and safety redundancy logic.
- Communication Module: Optional fieldbus or Ethernet interface card.
- Power Module: 24 V DC regulated power supply, with overvoltage/undervoltage protection.
5. Typical Application Fields
- Petrochemical & Chemical Industry: Pressure safety interlock, leakage protection, and Emergency Shutdown (ESD) systems.
- Oil & Natural Gas Industry: Pipeline pressure monitoring and safety control of oil-gas separation devices.
- Power & Electricity Generation Industry: Pressure monitoring of boilers and steam systems, and safety valve control.
- Metallurgy & Iron and Steel Industry: Safety monitoring of high-temperature and high-pressure furnaces.
- Pharmaceutical & Food Industry: Process pressure control in clean areas, meeting GMP requirements.
————————————————————————————————————-
