HIMA SB3073-EX safety barrier module
HIMA SB3073-EX
1. Overview
The HIMA SB3073-EX is a temperature transmitter-type isolated safety barrier. It is designed to convert resistance temperature detector (RTD) or thermocouple signals into standard 4–20mA/1–5V signals, achieving intrinsic safety isolation. This product is suitable for flammable and explosive environments, such as those in the chemical and petroleum industries. Its core function is to prevent dangerous energy from being transmitted back to on-site equipment, and it meets explosion-proof grade requirements (e.g., Ex ia II C).
2. Parameters
- Input/Output: It supports RTDs (Pt100, Cu50) or thermocouples (customization required). The output signals are 4–20mA or 1–5V, and the power supply is 24V DC±10%.
- Isolation Capability: It features three-port isolation (isolation between power supply, input, and output). The isolation voltage is ≥250V, the operating temperature ranges from -20℃ to 60℃, and the storage temperature ranges from -40℃ to 60℃.
- Dimensions and Weight: The approximate dimensions are 112.6×99×17.5mm, and the weight is about 150g (for DIN rail mounting).
3. Product Features
- Safety and Reliability: It adopts an intrinsic safety design, complies with explosion-proof standards (Ex ia II C), and is suitable for hazardous areas in Zone 0.
- Structure: It has a modular design and may adopt a hardware structure similar to that of HIMA safety control systems (e.g., HIMA F8627X and F3231 modules).
- Application Fields: It is applicable to flammable and explosive environments in industries such as chemical engineering, petroleum, and natural gas.
4. Structure and Composition
- Hardware Composition: It may include input/output modules, isolation circuits, power modules, etc., and refers to the modular design of HIMA safety control systems (e.g., HIMA F8627X and F3231 modules).
- Mounting Method: It may support DIN rail mounting, which complies with industrial equipment standards.
5. Application Fields
In industrial fields, it is used in scenarios that require temperature monitoring and safety control, such as the chemical, petroleum, natural gas, and pharmaceutical industries.
6. Installation and Maintenance
- Installation: The installation must follow the installation guidelines of HIMA or similar equipment (e.g., the installation steps of the F8627X module).
- Maintenance: Regular cleaning, inspection of connection lines, and monitoring of operating status are required to ensure compliance with electrical safety standards.
- Troubleshooting: For troubleshooting, refer to the fault diagnosis and codes in the HIMA safety control system manual.
————————————————————————————————————-
