HIMA X-FAN 18 03

The X-FAN 18 03 is an industrial forced air-cooling fan designed by HIMA for its X-Base Plate 18 01 (18-slot, redundant power supply). Each fan provides high-flow and low-noise forced ventilation, ensuring reliable heat dissipation for safety control cabinets, power modules, and other high-power electronic components in harsh industrial environments.

Main Technical Parameters

• Model: X-FAN 18 03 (corresponding part number: 993201813)
• Adaptable Base Plate: X-Base Plate 18 01 (4 fans used in parallel)
• Power Supply: 220 V AC (single-phase)
• Airflow: Approximately 300 m³/h (per unit)
• Noise Level: ≤ 45 dB(A)
• Protection Class: IP54, with dust and water resistance
• Structural Material: Corrosion-resistant metal housing, suitable for corrosive environments such as chemical industry and power generation
• Certification: ATEX (explosion-proof) certification, compliant with industrial safety standards

Product Features

• High Reliability: Specifically designed for safety instrumented systems, it has a redundant structure. A single unit failure will not affect the overall heat dissipation.
• Low-Noise Operation: The noise level is controlled below 45 dB, making it suitable for on-site locations with strict noise requirements.
• Protection and Explosion-Proof Performance: With IP54 protection class and ATEX explosion-proof certification, it can work safely in environments with dust, humidity, and flammable gases.
• Modular Installation: It can be directly snapped into the reserved fan slots of the X-Base Plate 18 01, enabling quick installation without additional wiring.
• Easy Maintenance: Equipped with a detachable filter screen, it facilitates regular cleaning and reduces maintenance costs.

Structure and Composition

• Fan Body: Integral structure consisting of motor, impeller, and housing.
• Power Terminal Block: Terminal block compliant with IEC standards, supporting quick wiring.
• Protective Filter Screen: Detachable metal filter screen to prevent dust from entering the interior of the fan.
• Fixing Bracket: Buckle structure matching the reserved card slots of the X-Base Plate.

Typical Application Fields

• Process industry control cabinets (oil refining, chemical industry, petrochemical industry, etc.)
• Power system distribution cabinets (substations, power plants)
• Machine tools and numerical control systems (heat dissipation for high-power drive modules)
• Nuclear power plant safety systems (key control units with explosion-proof requirements)
• Other industrial automation equipment requiring high-reliability heat dissipation

Key Points for Installation and Maintenance

Installation

Wiring

Commissioning

Regular Inspection

• Inspect the filter screen for blockage every 6 months; remove and clean or replace it if necessary.
• Check the tightness of bolts to prevent loosening due to vibration.

Troubleshooting

1. First, check the power supply and wiring.
2. Then, inspect the motor and impeller for foreign objects or wear.
3. Replace the entire unit if necessary.

————————————————————————————————————-
