Main Technical Parameters

• Model: Z7008/3238/Ex C5
• Operating Temperature: ‑25 °C ~ +70 °C (extendable to +85 °C as an option)
• Protection Level: IP20, Ex d IIC (explosion-proof)
• Power Supply: 24 V DC, power consumption ≤ 5 W
• Communication Interfaces: Multi-protocol support including PROFIBUS DP, PROFINET, Ethernet/IP, Modbus RTU/TCP, CAN open, etc.
• Redundancy: Dual CPU, dual bus redundancy, fault switching time ≤ 10 ms
• Dimensions: 5 U, 19-inch rack, DIN rail mounting
• Certifications: TÜV-RC 6, CE, ATEX, IECEx

Product Features

1. High Safety Level: Complies with SIL 3 / Cat 4 requirements, suitable for critical safety functions.
2. Multi-Protocol Compatibility: Supports switching between multiple fieldbuses and industrial Ethernet with one-time configuration, reducing system integration costs.
3. Redundant Design: Dual CPU and dual bus redundancy ensure uninterrupted communication and improve system reliability.
4. Explosion-Proof Structure: Certified to Ex d IIC, applicable to flammable and explosive sites.
5. Compact Installation: 5 U rack-mounted design, supporting quick assembly on DIN rails.
6. Easy Maintenance: Modular structure allows hot-swap replacement without shutdown; supporting diagnostic software enables fault location.

Structure and Composition

• Main Body: Metal housing, integrating dual CPUs, redundant power supplies, and communication processing units.
• Communication Cards: Optional cards for different protocols (PROFIBUS, PROFINET, Ethernet/IP, etc.), inserted and removed via the backplane.
• Power Module: 24 V DC input, internal voltage stabilization, and redundant power input.
• Diagnostic Interface: RS-232/RS-485, used for on-site debugging and fault diagnosis.
• Installation Accessories: DIN rail brackets, fixing screws, and terminal blocks.

Typical Application Fields

• Petroleum and petrochemical, natural gas, oil refining, and chemical raw material production
• Power and energy (power plants, distribution networks)
• Pharmaceutical and biotechnology
• Heavy industries such as iron and steel, cement, and papermaking
• Process Safety Instrumented Systems (SIS) and Emergency Shutdown (ESD) systems

Key Points for Installation and Maintenance

Installation

1. Fix the module using DIN rails according to the instruction manual, ensuring the rack is level.
2. Connect the 24 V DC power supply, and check the polarity and voltage range.
3. Select and insert the required communication cards into the backplane, ensuring the card slots are locked tightly.
4. Follow the IEC 61804 standard during wiring, and use explosion-proof junction boxes.

Debugging

1. Perform self-inspection using diagnostic software (e.g., HIMA Safety-Suite) to confirm the normal operation of redundant links.
2. Configure network parameters (IP, node address) and conduct fieldbus node scanning.

Daily Maintenance

1. Regularly check the power supply and heat dissipation holes for blockages, and maintain ventilation.
2. Conduct a functional self-inspection every 6 months and record logs for traceability.
3. In case of faults, use the hot-swap feature to replace faulty modules, allowing the system to complete switching without interruption.
