HIMA Z7108/3237/C5 Industrial Module
HIMA Z7108/3237/C5
HIMA Z7108/3237/C5 is an LED Indicator Cable Plug manufactured by HIMA, specifically designed for signal connection in industrial fieldbuses and Safety Instrumented Systems (SIS). Adopting a modular structure, this plug enables reliable electrical connections within DIN rail-mounted control cabinets, meeting the requirements for high reliability and Safety Integrity Level (SIL 3).
Key Specifications
- Model: Z7108/3237/C5
- Physical Dimensions: Compliant with DIN rail mounting standards, compact in size
- Operating Voltage: 24 V DC (commonly used industrial voltage)
- Operating Current: ≤ 0.5 A (current for LED indicators)
- Wiring Method: Screw-type or spring-clip type, supporting quick plug-and-unplug
- Protection Class: IP20 (dust-proof and electric shock-proof)
- Temperature Range: -25 °C ~ +70 °C
- Certifications: Compliant with the IEC 61508 functional safety standard, supporting SIL 3 certification
Product Features
- High Reliability: Features a fanless heat dissipation design, robust structure, and resistance to vibration and impact, making it suitable for harsh industrial sites.
- Modular Design: The plug can be modularly combined with matching LED indicators, facilitating replacement and expansion.
- Easy Installation: Supports DIN rail fixation and convenient plug-and-unplug operations, reducing on-site maintenance time.
- Safety Performance: Compliant with the IEC 61508 functional safety standard and meeting SIL 3 requirements, applicable to Safety Instrumented Systems (SIS).
- Compatibility with Multiple Communication Interfaces: Can be used with industrial communication protocols such as Modbus RTU, RS-485, and Ethernet.
Structure and Composition
- Housing: High-strength plastic or metal housing, providing mechanical protection.
- Pin Header: Metal pins treated with gold or silver plating to ensure low contact resistance.
- LED Indicator Module: Built-in indicators in colors such as red, yellow, and green for status display.
- Fixing Device: DIN rail clips or screw fasteners to ensure stable installation.
- Terminal Blocks: Screw-type or spring-clip terminals, supporting quick wiring.
Typical Application Fields
- Process Industry: Safety control in continuous production processes such as petrochemicals, chemicals, pharmaceuticals, steel, and cement.
- Energy and Power: Status indication for facilities like power plants, power distribution systems, wind power, and photovoltaic systems.
- Automation Systems: On-site signal indication and fault alarm for PLC, DCS, and SCADA systems.
- Mechanical Manufacturing: Equipment monitoring for production lines in automotive, textile, and mechanical processing industries.
Installation and Maintenance Guidelines
Pre-Installation Check
Confirm that the plug model and specifications match the DIN rail of the control cabinet, and check if the pins are in good condition.
Fixing Method
Use DIN rail clips or screws to securely fasten the plug to the rail, preventing loosening caused by vibration.
Wiring Operation
Connect signal wires to the corresponding terminals according to the wiring diagram, and use screws or spring clips to ensure reliable contact.
Functional Testing
After power-on, check if the LED indicators light up normally and verify the correctness of signal transmission.
Regular Maintenance
Conduct inspections every 6 ~ 12 months to remove dust, check the tightness of terminals, and replace aging LED modules if necessary.
Troubleshooting
If the indicator does not light up or the signal is abnormal, first check the power supply and wiring. If there is no looseness, replace the corresponding LED module or plug.
————————————————————————————————————-
If you would like to learn more about our products and services, please feel free to contact us at any time!
- Sales Manager : Jinny
- Email : sales5@xrjdcs.com
- Whatsapp/Mobile:+86 15359273791
