HIMA Z7136/3322/C5 Controller Module
HIMA Z7136/3322/C5
1. Overview
HIMA Z7136/3322/C5 is a safety controller module designed for hazardous industrial environments (such as chemical, petroleum, and natural gas industries). It adopts HIMA’s safety technology to implement highly configurable safety functions and meets the requirements of safety standards including IEC 61508/61511.
2. Specifications
- Power Supply: 24 V DC (supports redundant power supply)
- Operating Temperature: ‑20 °C ~ +60 °C (storage temperature ranges from ‑40 °C ~ +85 °C)
- Protection Class: IP20 (optional Ex‑C5 explosion‑proof enclosure)
- Digital I/O: 16 channels (configurable as input or output)
- Analog I/O: 2 channels (voltage/current)
- Communication Interfaces: Modbus RTU, RS‑232/RS‑485, Ethernet (optional PROFIBUS, PROFINET, Ethernet/IP, etc.)
- Dimensions: Approximately 120 mm × 70 mm × 110 mm
- Weight: ≈ 0.5 kg
3. Product Features
- Dual CPU Redundancy: Enables fault self‑detection and fault tolerance to ensure uninterrupted safety functions.
- Modular Design: Allows flexible addition or removal of I/O and communication cards based on on‑site requirements.
- Self‑Diagnostic Function: Built‑in diagnostic interface supports on‑site debugging and fault location.
- Compliance with Safety Standards: Meets the safety level requirements of IEC 61508/61511, EN ISO 13849, etc.
- Explosion‑Proof Option: Equipped with Ex‑C5 explosion‑proof enclosure, suitable for environments with flammable and explosive gases.
4. Structure and Composition
- Main Body: Features a metal enclosure, with dual CPUs, redundant power supplies, and a communication processing unit inside.
- Communication Cards: Removable cards that support multiple industrial protocols (PROFIBUS, PROFINET, Ethernet/IP, etc.).
- Power Module: Accepts 24 V DC input, provides internal voltage stabilization, and supports redundant power supply.
- Diagnostic Interface: RS‑232/RS‑485, used for on‑site debugging and fault diagnosis.
- Installation Accessories: Includes DIN rail brackets, fixing screws, terminal blocks, etc.
5. Application Fields
- Safety control in chemical processes
- Petroleum and natural gas production and transportation systems
- Safety monitoring of power and energy facilities
- Safety Instrumented Systems (SIS) in process automation systems
- On‑site locations requiring explosion‑proof certification (Ex‑C5)
6. Installation and Maintenance
- Installation: Fixed using DIN rails to ensure horizontal installation of the chassis; terminal blocks are clearly labeled for quick wiring.
- Wiring: Comply with electrical specifications—disconnect power before wiring; assign digital I/O and analog I/O according to requirements.
- Debugging: Conduct on‑site debugging via the built‑in diagnostic interface (RS‑232/RS‑485); use the configuration software provided by HIMA for parameter setting and function verification.
- Maintenance: Regularly inspect the power supply, heat dissipation holes, and connection terminals; use the self‑diagnostic function to monitor the health status of the module and replace faulty components in a timely manner.
————————————————————————————————————-
