HIMA Z7138/3330/C5 Expansion Accessories

Short Description:

HIMA Z7138/3330/C5 is a highly specialized communication interface module or system expansion accessory designed by Germany-based HIMA for its modular safety control systems (such as the HIMatrix® or Planned series). The composite coding of this model indicates that it is a functional unit with a specific configuration, typically serving as a bridge between the main controller and external systems or dedicated networks.

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Brand: HIMA

Manager: Jinny

E-mail: sales5@xrjdcs.com

Tel: + 86-15359273791

( WhatsApp )Wechat: + 86-15359273791

Warranty: one year

In stock: In stock

Send email to us Download as PDF

Product Detail

Product Tags

HIMA Z7138/3330/C5

1. Product Overview

The core function of HIMA Z7138/3330/C5 is to enable reliable data exchange between the safety controller and upper-level management systems (e.g., DCS), third-party PLCs, or specific field devices, ensuring that safety-critical information is accurately transmitted and shared. In automated systems, it is positioned as a core node for network connectivity, and its core value lies in breaking down information silos. On the premise of ensuring the Safety Integrity Level (SIL), it realizes efficient and reliable integration of safety systems and process control systems, thereby providing operators with a complete plant view and supporting higher-level decision-making and coordination.

2. Product Parameters

Product Model: Z7138/3330/C5
Manufacturer: HIMA
Product Type: Communication Interface Module or System Expansion Module
Main Functions: Protocol conversion, network gateway, I/O expansion (depending on specific configuration)
Interface Type: Typically includes Ethernet, serial interfaces (RS485/RS232), or dedicated bus interfaces
Supported Protocols: May support Modbus TCP/IP, Modbus RTU, OPC, PROFIBUS, HIMA-specific protocols, etc.
Power Requirement: 24V DC (usually supplied by the system backplane or an external power source)
Power Consumption: Typically < 5W
Operating Temperature: 0°C to +60°C (industrial standard range)
Installation Method: DIN rail mounting or fixed to a dedicated base
Certifications: Compliant with relevant industrial Electromagnetic Compatibility (EMC) and safety standards

3. Structure and Composition

The HIMA Z7138/3330/C5 module adopts a robust industrial-grade metal or high-strength plastic housing to ensure its mechanical strength and Electromagnetic Interference (EMC) resistance. The front of the module is usually equipped with a series of LED status indicators, which are used to display power supply, communication activity, data transmission/reception, and fault status in real time.

Its internal core is a high-density Printed Circuit Board (PCB) integrated with a dedicated communication processor (CP), memory, and protocol stack chips. Depending on its functional definition, the module is equipped with one or more physical communication interfaces, such as RJ45 Ethernet ports, DB9 serial ports, or pluggable terminal block connectors. These interfaces work in collaboration with the main processor via an internal bus.

The module is connected to the backplane or base of the HIMA system (e.g., HIMA F 7120) through a connector at the bottom or rear, enabling high-speed and secure data interaction with the HIMA F 3×100 series CPU.

4. Application Fields

The HIMA Z7138/3330/C5 module is widely used in various industrial fields that require integrating Safety Instrumented System (SIS) information into broader control and management networks.

In the oil, gas, and chemical industries: It is used to connect HIMA safety controllers and Distributed Control Systems (DCS), uploading real-time alarm, status, and process shutdown signals from Emergency Shutdown (ESD) and Fire & Gas (F&G) systems to the central control room, allowing operators to fully grasp safety conditions.
In the energy and power industry: It is used to integrate data from Furnace Safety Supervision System (FSSS) or turbine protection systems into the power plant’s main control system (SIS/MIS).
In large-scale manufacturing and assembly lines: HIMA Z7138/3330/C5 can connect data from safety controllers to Manufacturing Execution Systems (MES), realizing synergy between production safety and efficiency management.

5. Installation and Maintenance

5.1 Pre-Installation Preparation

Before installing the HIMA Z7138/3330/C5 module, ensure that the power supply of the entire HIMA system is completely turned off. Verify that the module’s order number and hardware version are consistent with the design documents. Plan the network topology, prepare industrial-standard network cables (e.g., Category 5e shielded network cables) or serial communication cables, and ensure that the configuration of relevant network devices (e.g., switches) is completed.

5.2 Maintenance Recommendations

Maintenance of this module mainly focuses on status monitoring:

Regularly observe the module’s LED indicators to confirm that the communication link is active and free of error alarms.
Use HIMA’s configuration software to regularly check communication diagnostic counters, paying attention to abnormalities such as CRC errors and timeouts.
Keep the communication ports clean to prevent dust and moisture from entering.
Before making any changes to network connections, temporarily disable the relevant communication functions in the software to avoid generating a large number of communication error logs.
If the module needs to be replaced, the original configuration scheme usually needs to be downloaded to the new module.

————————————————————————————————————-
