1. Overview

2. Technical Parameters

• Safety Level: Complies with IEC 61508/61511 standards, supports SIL 3 certification, and some models support SIL 4.
• Redundant Structure: Quadruple redundancy (4oo4), ensuring safe system shutdown even in the event of multiple simultaneous faults.
• Processor: High-reliability industrial-grade processor with Real-Time Operating System (RTOS) capability, adjustable scanning speed (usually between 10ms and 100ms).
• Communication Interfaces: Supports multiple industrial communication protocols such as Profibus, Modbus, CAN, Ethernet/IP, PROFINET, and DeviceNet, facilitating integration with DCS and SCADA systems.
• Power Supply: Typically equipped with dual power input, supporting 24VDC or 230VAC, with power failure recovery function (safe power failure recovery).
• Environmental Adaptability: Operating temperature range is usually -20℃ to +60℃, with protection level IP20 or higher.

_______________________________________________________________________________________________________

3. Product Features

• Extremely High Reliability: Quadruple redundancy architecture and self-diagnostic function enable continuous safe operation even when part of the system’s hardware fails.
• Complete Safety Functions: Built-in Fail-Safe function, which can force cut off the output or keep it in a safe state even in the event of abnormal faults.
• Strong Anti-Interference Ability: Specifically designed for harsh industrial on-site environments, with high anti-electromagnetic interference capability.
• Modular Design: Supports modular I/O expansion, allowing users to configure digital, analog, and counter modules according to on-site needs.
• Compatibility: Supports multiple communication protocols, making it easy to integrate into existing factory automation systems.

_______________________________________________________________________________________________________

4. Structure and Composition

• CPU Module: Core control unit, including redundant processors and system memory.
• Communication Module: Provides fieldbus or Ethernet interfaces and supports different network protocols.
• I/O Modules: Including digital input/output, analog input/output, counter/timer modules, etc., usually installed in rack or panel type.
• Power Supply Module: Provides stable working power and has power failure monitoring function.

_______________________________________________________________________________________________________

5. Application Fields

• Oil and Gas: Oil-gas separation, compressor start-up protection, safety interlocking in explosive hazardous areas.
• Chemical and Pharmaceutical: Hazardous chemical storage tank control, reactor safety protection, safety interlocking of key valves.
• Energy and Power: Generator set safe shutdown, boiler safety control, nuclear power plant safety system.
• Metallurgy: High-temperature furnace monitoring, continuous caster safety interlocking.

_______________________________________________________________________________________________________

6. Installation and Maintenance

Installation

• DIN Rail Installation: Usually supports DIN rail or rack installation, facilitating layout in the control cabinet.
• Wiring Specifications: Strictly follow industrial electrical standards to ensure good shielding and grounding of signal lines to prevent interference.
• Communication Configuration: Configure communication parameters according to fieldbus standards (such as Profibus, Ethernet/IP).

Maintenance

• Regular Self-Inspection: The equipment is equipped with a self-diagnostic function that records hardware fault logs. Operation and maintenance personnel need to regularly check the system diagnostic report.
• Redundancy Check: Regularly verify the consistency of redundant modules to ensure that the redundant backup can take over immediately in case of a single point of failure.
• Firmware Update: Firmware upgrades must be obtained through official HIMA channels, and the upgrade process must strictly follow safety specifications.

————————————————————————————————————-
