Schneider 140CPU67261 Expansion Unit
Schneider 140CPU67261
1. Overview
The 140CPU67261 is a hot standby processor of the Modicon Quantum series, serving as an expansion unit for Modicon M340/M580 series controllers. It is usually paired with a master processor (such as 140CPU67260) to form a master-standby dual-machine redundant structure. This processor is mainly used in industrial scenarios with extremely high requirements for system operation safety.
_______________________________________________________________________________________________________
2. Key Technical Parameters
|
Parameter
|
Parameter Value
|
Remarks
|
|---|---|---|
|
Model
|
140CPU67261
|
Hot standby processor model
|
|
CPU
|
PowerPC 604e
|
Clock speed is about 400MHz, supporting efficient operation processing
|
|
Memory
|
3072KB RAM + 128KB Flash
|
Note: This model usually has no independent I/O expansion capacity, mainly used for status monitoring and hot standby switching; the main I/O processing capacity is on the master processor
|
|
Communication Interface
|
Multiple (Ethernet, Serial, CAN, Modbus, Profibus)
|
Specific interfaces depend on the specific version, usually supporting hot standby protocol
|
|
Operating Temperature
|
-10℃ – 55℃
|
Industrial-grade environment
|
|
Power Supply
|
24V DC
|
Same power supply system as the master processor
|
_______________________________________________________________________________________________________
3. Core Product Features
Hot Standby Redundancy Function (HSP)
- The core function is to monitor the status of the master processor (such as CPU usage, memory status, network communication status).
- When the master processor fails (such as hardware damage, system hang), the hot standby processor will automatically take over the control task, realizing seamless system switching and avoiding production interruption.
- Application Scenarios: Chemical, petroleum, electric power and other industries where shutdown consequences are serious.
_______________________________________________________________________________________________________
High Reliability
- Adopts redundant architecture design and has passed strict industrial-grade testing.
- Supports multiple network protocols, facilitating integration with different field bus systems.
_______________________________________________________________________________________________________
Easy Programming and Monitoring
- Configuration and monitoring are performed through Schneider’s SoMachine (Unity Pro) software.
- Supports multiple programming languages such as Structured Text, Ladder Diagram, and Function Block Diagram, facilitating debugging by maintenance personnel.
_______________________________________________________________________________________________________
4. Structure and Composition
- CPU Motherboard: Contains the core processor and memory.
- Communication Interface Card: Configure Ethernet, Serial, CAN and other interfaces as needed for communication with the master processor or on-site equipment.
- Hot Standby Protocol Circuit: Used to exchange status information (Heartbeat) with the master processor in real time.
_______________________________________________________________________________________________________
5. Typical Application Fields
- Petrochemical Industry: Control of key oil refining and chemical equipment.
- Power System: Power plant control systems, substation automation.
- Large-scale Building Automation: Power supply and refrigeration systems for important computer rooms, data centers, and hospitals.
- Iron and Steel & Metal Processing: High-risk processes such as blast furnaces and continuous casting.
- Rail Transit: Train signal systems and locomotive control.
_______________________________________________________________________________________________________
6. Installation and Maintenance Recommendations
Installation
- Use it in pairs with the master processor and ensure it is installed on the same rack.
- Connect the power cord and communication cable to ensure the connectivity of the Hot Standby Protocol.
- Pay attention to anti-static operations when plugging and unplugging modules.
Maintenance
- Regularly check the status lights of the hot standby processor (usually red and green lights indicate the working status).
- Use SoMachine software to monitor the hot standby switching log to ensure the standby machine is in standby state.
- It is recommended to conduct a hot standby switching test every year to verify whether the standby machine can take over successfully.
————————————————————————————————————-
