Schneider 47060 NT/NW Digital Power Meter
Schneider 47060 NT/NW
1. Overview
Schneider 47060 NT/NW is a high-precision digital energy meter (Micrologic 6.0 E) produced by Schneider Electric, specifically designed for the MASTERPACT NT/NW system. It is mainly used to measure electrical parameters such as electrical energy, power factor, and frequency, and supports local or remote communication.
_______________________________________________________________________________________________________
2. Specification Parameters
- Measurement Type: Energy Meter
- Ambient Operating Temperature: -25℃ to 70℃
- Ambient Storage Temperature: -40℃ to 85℃
- Display Type: Digital Display
- Protection Level: Complies with NEMA 4/4X/13 Standards (dust-proof, water-proof, chemical corrosion-resistant)
- Dimensions: Height 6.8 cm, Width 8.0 cm, Length 21.5 cm
- Weight: Approximately 347 grams
- Power Supply Requirement: Usually 24V DC power supply
- Communication Interface: Supports MODBUS/RS485 Communication
- Product Code: ZB6AE1
- Warranty Period: 18 Months
_______________________________________________________________________________________________________
3. Product Features
- High-Precision Measurement: Adopts high-precision measurement chip to ensure the accuracy of electrical energy data.
- Multi-Functional Display: Supports local digital display, which can intuitively show key parameters such as voltage, current, and power.
- Remote Monitoring: Through the MODBUS protocol, data can be uploaded to the upper computer to realize remote monitoring and management.
- Industrial-Grade Design: With IP65 protection level, it is suitable for harsh industrial environments.
_______________________________________________________________________________________________________
4. Structure and Composition
- Meter Main Body: Includes LCD display, key panel and internal circuit board of the meter.
- Mounting Bracket: Usually equipped with a mounting bracket or adapter for easy embedded or wall-mounted installation.
- Terminal Blocks: Terminal blocks for power lines and load lines.
- Communication Interface: RS485 interface for connecting to the upper computer.
_______________________________________________________________________________________________________
5. Application Fields
- Industrial Automation: Used to monitor the electrical energy consumption of factory workshops.
- Power Distribution System: Used for electrical energy measurement in substations or power distribution cabinets.
- Building Management: Used for electrical energy monitoring in building automation systems.
_______________________________________________________________________________________________________
6. Installation and Maintenance
Installation
- Environmental Requirements: Ensure that the installation environment meets the IP65 protection level, and avoid exposure to corrosive gases or high-temperature environments.
- Wiring: Correctly connect the power lines and load lines, and ensure the correct direction of the Current Transformer (CT).
- Communication Connection: If using the remote monitoring function, it is necessary to connect the RS485 bus and set the correct baud rate.
Maintenance
- Regular Calibration: To ensure measurement accuracy, regular calibration is recommended.
- Cleaning: Keep the surface of the meter clean to prevent dust from affecting heat dissipation.
- Fault Indication: The meter itself is usually equipped with a fault indicator light. If a fault occurs, it can be diagnosed through the error code on the display or the indicator light.
————————————————————————————————————-
