Schneider AEG AS-B882-239 I/O Module
Schneider AEG AS-B882-239
1. Overview
2. Key Technical Parameters
| Parameter | Detailed Specification |
|---|---|
| Model | AS-B882-239 |
| Function Type | Counting/Positioning Module (AI/DO/CI) |
| Number of Counters | 2 independent counters |
| Counting Frequency | Up to 30 kHz (High-frequency Mode); 350 Hz (Low-frequency Mode) |
| Count/Reset Pulse Width | 13 µs (Min, High-frequency Mode); 1.3 µs (Max, Low-frequency Mode) |
| Auxiliary Input (AI) | 6 channels |
| Digital Output (DO) | 6 channels |
| Power Supply Requirement | +5 Vdc: 188 mA (Typical Value); +4.3 Vdc: 0 mA |
| Dimension/Weight | 1 slot, approx. 1.34 kg |
| Certification | Compliant with industrial standards |
3. Product Features
- High-precision Counting: Supports counting frequency up to 30 kHz, ideal for accurate counting of high-speed rotating equipment or fast pulse signals.
- Flexible Counting Modes: Compatible with multiple counting methods (e.g., rising edge, falling edge, double-edge counting) to adapt to different sensor signals.
- Rich I/O Interfaces: Equipped with 6 auxiliary inputs and 6 outputs, facilitating interaction with external devices (such as buttons and signal lights).
- Compact Design: Adopts 1-slot structure to save cabinet space, suitable for rack mounting.
- High Reliability: Meets industrial environment requirements and is applicable to harsh working conditions.
4. Structure & Composition
- Counter Core: Responsible for processing counting logic and storing count values.
- I/O Terminal Block: Used to connect external sensor signals (input) and control signals (output).
- Power Supply Module: Provides power for the internal circuit of the module.
- Communication Interface: Supports communication with Modicon Quantum host CPU to realize data exchange and command control.
5. Application Fields
- Packaging Industry: Counting control of bottling, canning and packaging lines.
- Printing & Sorting: Paper or product counting for printing machines and sorting machines.
- Machining: Rotational speed counting of machine tools or counting of workpieces.
- Conveying Systems: Material counting on conveyor belts.
- Motor Control: Motor speed counting or position positioning.
6. Installation & Maintenance
Installation Recommendations
- Power Connection: Ensure correct wiring of the module power supply (+5 Vdc) and comply with electrical specifications.
- Terminal Connection: Input signals generally require a specific voltage range (e.g., 24VDC), and output signals need to match load requirements.
- Communication Configuration: In the Modicon Quantum system, add the module in programming software (e.g., Unity Pro) and map the I/O addresses.
Maintenance Essentials
- Regular Inspection: Check terminal blocks for looseness, corrosion or moisture.
- Environmental Control: Avoid overheating of the module and ensure good heat dissipation inside the cabinet.
- Software Update: Pay attention to firmware updates from Schneider Electric to ensure module compatibility and security.
