Schneider AEG AS-P810-000 Power Module
Schneider AEG S74D-V00-F0V0
AS-P810-000 is a power supply module launched by Schneider Electric for Modicon 984 series PLCs. It delivers stable 24V DC power supply to ensure the reliable operation of PLC systems in industrial sites. Featuring a compact DIN rail-mounted structure, this module is ideal for installation in control cabinets with limited space.
Main Technical Specifications
Rated input voltage: 24V DCPower consumption: Approximately 2.5 VA, with high conversion efficiency and low heat generationOutput characteristics: Low ripple, overload and short-circuit protection; optional output relays (1 normally open or 1 normally closed), rated at 250V AC/2A (resistive load)Operating temperature: -20 °C to +55 °CProtection class: IP20, suitable for general industrial environmentsDimensions/Weight: Approximately 80 mm × 130 mm × 40 mm, weighing around 0.5 kg
Product Features
High reliability: Adopts high-quality components with built-in overload and short-circuit protection to prevent system shutdown caused by power failures.High efficiency: Excellent conversion efficiency reduces energy consumption and heat dissipation, extending the overall service life of the system.Wide input range: Compatible with various industrial power supplies, adapting to different on-site power supply conditions.Compact design: DIN rail mounting takes up minimal space, facilitating layout in densely packed control cabinets.Easy maintenance: Modular structure enables quick replacement in case of faults, supporting on-site diagnosis and monitoring functions.
Structure & Components
Power conversion unit: Responsible for AC-DC or DC-DC conversion, providing stable 24V DC output.Protection circuit: Equipped with multiple protection modules including overload, short-circuit, overvoltage and undervoltage protection.Output relay: Optional normally open or normally closed configuration to meet different load requirements.Heat sink & enclosure: Metal enclosure combined with heat sink ensures the operating temperature stays within a safe range.Terminal block: Standardized terminal block for quick wiring and inspection.
Typical Application Fields
Industrial automation: Scenarios requiring reliable PLC power supplies such as manufacturing, process control, packaging and material handling.Machine vision & motion control: Systems sensitive to power supply noise.Energy management & power distribution: Cooperates with low-voltage distribution cabinets to realize centralized power supply and monitoring.
Installation & Maintenance Key Points
Installation method: Fixed via DIN rail; ensure horizontal installation of the module to avoid contact issues caused by vibration.Wiring requirements: Follow the wiring diagram in the product manual; install anti-reverse connection diodes at the input end and use wires matching the rated current at the output end.Environmental requirements: Operate within the specified temperature range; IP20 protection class applies to dust-free and dry indoor environments. A protective cover is required for use in humid or dusty environments.Inspection & testing: Check wiring correctness before first power-on; use a multimeter to verify that output voltage and ripple meet specifications; regularly inspect heat sinks for dust accumulation.Troubleshooting: The module is equipped with diagnostic indicator lights. In case of abnormality, error codes can be read via the PLC’s diagnostic function to quickly identify overload, short-circuit or power supply anomalies.Replacement & maintenance: Modular design allows quick plug-and-play replacement on site. A comprehensive inspection is recommended every 2-3 years to ensure no loose fasteners and clean heat sinks.
————————————————————————————————————-
