1. Overview

2. Technical Specifications

• Rated Power: 90 kW (125 hp)
• Input Voltage: 380-480 V (Three-phase)
• Output Frequency Range: 0 – 500 Hz (Adjustable)
• Control Modes: V/F, Sensorless Vector, Closed-loop Vector
• Overload Capacity: 150% rated current for 1 minute
• Protection Class: IP21 (Standard), Optional IP54 / IP65
• Operating Temperature Range: -10°C to +50°C (Derating required for DIN rail mounting)
• Communication Interfaces: Modbus, CANopen, Profibus DP, EtherNet/IP, etc.
• Braking Unit: Supports external braking resistors (e.g., BTV series) for rapid braking

_______________________________________________________________________________________________________

3. Product Features

• High Efficiency: Adopts advanced power semiconductors and control algorithms to reduce energy consumption and improve overall system efficiency.
• Multiple Control Modes: Compatible with various control methods to meet the needs of different types of load control.
• Flexible Communication Capability: Supports multiple industrial fieldbuses and Ethernet protocols, facilitating integration with PLC, DCS or SCADA systems.
• Strong Overload Resistance: 150% rated current overload capacity (for 1 minute) to cope with transient shock loads.
• Advanced Braking System: Optional braking unit solutions for mechanical systems requiring rapid stopping.

_______________________________________________________________________________________________________

4. Structure and Composition

• Power Circuit: Includes power semiconductors (IGBT/MOSFET), rectifier filters, inverter bridges, etc.
• Control Unit: Microprocessor or DSP chip, used to implement control functions such as speed regulation and fault detection.
• Communication Module: Located on the side or back panel, providing multiple industrial protocol interfaces.
• Braking Unit Interface: Used to connect external braking resistors or brakes (e.g., BTV series).
• Cooling System: Internal fans or heat sinks to maintain the operating temperature of power modules.

_______________________________________________________________________________________________________

5. Application Areas

• Pump Control: Large-flow pump stations for water supply, wastewater treatment, oil transportation, etc.
• Fans and Compressors: Mine ventilation, air compression, petrochemical and other industries.
• Metallurgy and Mining: Steel, copper smelting and ore processing equipment.
• Power Systems: Generator set speed regulation, synchronous motor control, etc.
• Building Facilities: Large-scale HVAC systems, heating systems.

_______________________________________________________________________________________________________

6. Installation and Maintenance

Installation Method

• Vertical Installation: Vertical installation is usually adopted, which requires good ventilation and avoids direct sunlight.
• Heat Dissipation Space: Reserve at least 100mm of heat dissipation space on the top, bottom, left and right during installation to prevent overheating.

Wiring Requirements

• Main Circuit: Connect L1/L2/L3 to the input terminal, U/V/W to the output terminal, and PE as the ground wire.
• Control Circuit: Provides 24V DC power supply, including Digital Input/Output (DI/DO) and Analog Input/Output (AI/AO).
• Braking Resistor: If the load requires rapid braking, an external braking unit (e.g., BTV series) is required.

Environmental Adaptability

• Temperature Control: The operating temperature range is -10°C to +50°C, and derating is required according to the ambient temperature when mounted on DIN rails.
• Protection Class: The standard protection class is IP21; for use in humid or dusty environments, please select the IP54 or IP65 version.

————————————————————————————————————-
