Schneider ATV930D90N4 frequency converter
Schneider ATV930D90N4
Product Overview
The Schneider ATV930D90N4 is a high-performance Variable Frequency Drive (VFD) engineered bySchneider Electric, a global leader in energy management and industrial automation. This premium drive is designed to precisely control motor speed and torque, delivering exceptional energy savings and optimized process performance across diverse industrial scenarios.
______________________________________________________________________________________________________________
Tailored for 90kW (approximately 120hp) heavy-duty industrial applications, the ATV930D90N4 supports400/480V three-phase power input, making it compatible with standard industrial power supplies. It comes equipped with a built-in braking unit, boasts an IP21 ingress protection rating, and is ideally suited for indoor industrial environments such as workshops, manufacturing facilities and production lines, ensuring stable operation in controlled working conditions.
Key Technical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Model
|
ATV930D90N4
|
|
Rated Power
|
90kW
|
|
Input Voltage
|
400/480V (Three-Phase)
|
|
Ingress Protection Rating
|
IP21 (IP20 cabinet-mounted type optional)
|
|
Braking Unit
|
Standard configuration (including braking resistor)
|
|
Mounting Method
|
Vertical installation (±10° deviation allowed)
|
|
Operating Temperature
|
-15°C to +50°C (no derating required)
|
|
Storage Temperature
|
-40°C to +70°C
|
|
Compatible Motors
|
Asynchronous motors, synchronous motors (including permanent magnet synchronous motors)
|
|
Control Modes
|
V/F control, vector control, sensorless vector control, closed-loop vector control
|
|
Dimensions (W x H x L)
|
Approx. 290mm x 322.5mm x 922mm (Reference Source)
|
Product Features & Advantages
Energy-Saving & High Efficiency
Integrated with advanced vector control technology, the ATV930D90N4 optimizes motor efficiency dynamically under varying load conditions, eliminating unnecessary energy waste and significantly reducing overall power consumption for industrial operations. This core advantage helps enterprises cut energy costs and achieve greener production targets.
Superior Safety & Reliability
This drive complies with rigorous international safety standards, including EN 954-1 Category 1 and IEC/EN 61508 SIL1, guaranteeing reliable operational safety. It is equipped with the Safe Torque Off (STO) function, which effectively cuts off motor torque during equipment maintenance and overhaul, eliminating potential safety hazards and protecting on-site operators.
Flexible & Adaptive Control
The drive supports diversified control logics and comprehensive I/O configurations, covering digital input/output, analog input/output, reference potentiometers and more. This high degree of flexibility enables seamless integration with complex industrial automation systems, meeting customized control demands across different application scenarios.
Efficient Braking Performance
With a standard built-in braking unit, the ATV930D90N4 enables rapid and stable motor deceleration and stopping. It is perfectly suited for applications requiring quick braking or energy feedback, enhancing operational responsiveness and system stability for high-dynamic equipment.
Eco-Friendly & Sustainable Design
Aligned with global environmental protection requirements, the product holds RoHS and REACH certifications and participates in Schneider Electric’s Green Premium program. It adopts sustainable design concepts, reducing environmental impact throughout the product lifecycle while meeting industrial sustainability benchmarks.
Structure & Components
- Power Module: The core component responsible for power conversion and precise regulation, ensuring stable power output and efficient motor driving.
- Controller: Built-in high-performance CPU that executes advanced motion control algorithms, delivering accurate and responsive motor speed and torque regulation.
- Braking Unit: Comprises braking resistors and dedicated wiring terminals, enabling effective energy feedback and reliable motor braking control.
- Input/Output Terminals: Standardized terminals for connecting power supplies, motors, sensors and external control equipment, facilitating easy wiring and system integration.
- Cooling Fan: Delivers efficient heat dissipation through natural convection or forced convection, maintaining optimal operating temperature and extending equipment service life.
Application Industries & Scenarios
The Schneider ATV930D90N4 VFD is a versatile industrial drive suitable for a wide range of heavy-duty and general industrial applications, including but not limited to:
- Pumps & Fans: Water treatment systems, petroleum drilling equipment, compressed air systems, HVAC fans and industrial water pumps.
- Processing Machinery: Injection molding machines, die-casting machines, textile machinery, packaging machinery and other processing equipment.
- Conveying Systems: Industrial conveyor belts, elevators, hoists and material handling systems.
- Mining & Metal Smelting: High-power heavy-duty driving equipment for mining operations, metal smelting and mineral processing.
- Food & Beverage: Cleaning, mixing, pumping and other automated production processes in food and beverage manufacturing lines.
————————————————————————————————————-
