Schneider BMEH584040 Processor Module
Schneider BMEH584040
1. Overview
The BMEH584040 is a high-end processor module that supports redundancy (hot backup), mainly used in critical industrial control systems. It is compatible with multiple communication protocols (such as TCP/IP, EtherNet/IP, AS-Interface) and is suitable for environments requiring high availability and network security.
_______________________________________________________________________________________________________
2. Parameters & Technical Specifications
Memory & Storage
- Program Memory: 16MB RAM
- Data Memory: 204KB RAM
- Expandable Flash Memory: Up to 4GB
Communication Interfaces
- 1 Ethernet TCP/IP for Service Port
- 2 Ethernet TCP/IP for Device Network
- USB Interface
- HSBY Port
- Supports up to 61 Ethernet devices and 16 Remote IO Racks (X80 and Quantum IO)
Dimensions & Weight
- Dimensions: 130.3mm × 134.6mm × 64.6mm (compared to other models of approximately 90x80x62mm)
- Weight: Approximately 0.889kg
_______________________________________________________________________________________________________
3. Product Features
- Redundant Design: Supports redundant configuration to ensure the system continues to operate in the event of a single point of failure, improving system reliability.
- High Performance: Adopts advanced processor technology with fast processing speed (approximately 0.72-16.3μs), suitable for real-time control requirements.
- Network Security: Supports AS-Interface safety protocol, suitable for explosive environments (ATEX Cat. 3G gas, 3D dust).
- Strong Environmental Adaptability: Operating temperature range is -25°C to 60°C, storage temperature range is -40°C to 85°C, vibration resistance of 3gn, and shock resistance of 30gn.
_______________________________________________________________________________________________________
4. Structure & Composition
The module usually adopts a 4-Level design, with redundant power supply and redundant CPU, and is installed in a rack-mounted manner. It internally includes rich I/O interfaces, a processor core, memory modules, and communication modules.
_______________________________________________________________________________________________________
5. Application Fields
- Industrial Automation: Such as production line control, robot control systems, etc.
- Process Control: Industries requiring high reliability such as petroleum, chemical industry, and electric power.
- Network Security Management: Data transmission and control systems requiring high security.
_______________________________________________________________________________________________________
6. Installation & Maintenance
Installation
It is usually installed in a rack-mounted manner, and wall-mounted or front-mounted installation is not supported. During installation, ensure that the rack space is sufficient and the surrounding environment meets the ventilation and heat dissipation requirements.
Maintenance
It is recommended to regularly check the rack connection status and heat dissipation, and monitor the operation status of the power supply and CPU. Since it supports redundant configuration, the switching mechanism of the redundant system should be focused on during daily maintenance to ensure it is normal.
————————————————————————————————————-
