Schneider IC65N2PC20A+VIGI2P40A Air Circuit Breaker
Schneider IC65N2PC20A+VIGI2P40A
I. Product Overview
The IC65N2PC20A is a 2-pole 20A Miniature Circuit Breaker (MCB) launched by Schneider Electric, belonging to the IC65 series. It holds the Green Premium™ certification, complies with REACH regulations, and is mercury-free, making it ideal for overload protection in power distribution circuits of residential, commercial, and light industrial applications.
The VIGI 2P40A is a 2-pole 40A Current Transformer (CT) from the same series. It works with protective relays to realize functions such as current monitoring, power metering, and residual current protection. These two products are often used in combination, forming the basic protection unit of low-voltage distribution cabinets.
II. Main Technical Specifications
| Specifications | IC65N2PC20A (Circuit Breaker) | VIGI 2P40A (Current Transformer) |
|---|---|---|
| Rated Current | 20A | 40A |
| Pole Number | 2P | 2P |
| Rated Voltage | 230/400V AC | 230/400V AC |
| Short-Circuit Breaking Capacity | 6kA (IC65 series standard) | – |
| Contact Material | Copper alloy with silver plating | – |
| Environmental Mark | Green Premium™, REACH compliant | – |
| Warranty Period | 18 months | 18 months |
| Dimensions | Miniature MCB form factor (approx. 35mm width) | CT form factor compatible with corresponding circuit breakers |
| Installation Method | DIN rail or panel-mounted | DIN rail-mounted, snap-in fixing |
III. Product Features
- Eco-Friendly Design: Mercury-free materials compliant with REACH regulations, holding the Green Premium™ certification.
- High Reliability: Copper alloy contacts with silver plating ensure low contact resistance and long service life.
- Compact Size: Miniaturized design suitable for distribution cabinets or panels with limited space.
- Easy Maintenance: Visual indicator lights and manual reset mechanism enable quick fault location and power restoration.
- Strong Compatibility: Seamless integration with VIGI series current transformers, protective relays, PLCs, and other automation components.
IV. Structure and Composition
- Circuit Breaker (IC65N2PC20A): Housing, 2-pole contacts, spring reset mechanism, handle/indicator light, and rail mounting clips.
- Current Transformer (VIGI 2P40A): Iron core, primary side conductor, secondary side output terminals, mounting clips, and insulating sleeve.
Both products adopt a modular structure, facilitating quick on-site assembly or replacement.
V. Typical Application Fields
- Power distribution branch circuits in residential and commercial buildings
- Small industrial equipment (e.g., CNC machine tools, packaging lines)
- Power distribution protection in computer rooms and data centers
- Current monitoring and power metering of power supply systems
- Intelligent power distribution solutions integrated with PLC and SCADA systems
VI. Installation and Maintenance Guidelines
Installation
- Confirm that the distribution cabinet or panel meets DIN rail specifications.
- Insert the IC65N2PC20A into the rail and secure it with clips; repeat the same process for the VIGI 2P40A.
- During wiring: Connect the L and N terminals of the circuit breaker to the power phase and neutral lines respectively; connect the primary side of the CT in series with the measured circuit, and the secondary side to protective relays or metering instruments.
- Check that all screws and clips are tightly fastened to avoid looseness.
Commissioning
- Reset the circuit breaker handle and verify that the indicator light functions normally.
- Perform secondary side current calibration for the CT (e.g., using an ammeter or relay calibration function) to ensure the ratio coefficient is 40A/5A (standard ratio).
Daily Maintenance
- Regularly inspect the circuit breaker handle and indicator light for abnormalities; clean dust if necessary.
- Check the tightness of the CT’s primary side conductor to prevent measurement errors caused by looseness.
- In case of tripping, first check for overload or short circuit in the load; replace the circuit breaker if necessary.
Replacement
- After power-off, use special tools to pull out the old circuit breaker or CT, and directly insert a new product of the same specification.
- Conduct a complete functional test after replacement to confirm normal protection actions.
————————————————————————————————————-
