1. Overview

2. Key Technical Specifications

3. Core Product Features

• Full Power Parameter Measurement: This meter is capable of measuring not only active power, reactive power, apparent power, current, voltage and power factor, but also monitoring power quality indicators including THD/TDD, covering comprehensive electrical parameter detection to meet diversified monitoring needs.
• Advanced Alarm Function: Built-in 30 types of advanced alarm events, enabling real-time monitoring of power grid operating status, timely detecting abnormal electrical conditions, and effectively preventing electrical accidents and equipment failures to ensure the stable operation of power distribution systems.
• Historical Data Storage: Supports the storage of 40 historical event records, providing complete data support for post-event fault analysis, cause tracing and system optimization, which is crucial for troubleshooting and operational improvement.
• Metering Security: Equipped with a photoelectric seal switch that strictly complies with relevant electrical energy metering regulations, preventing unauthorized data tampering and ensuring the authenticity, integrity and legibility of metering data.
• Compact Design: Features a small and lightweight size, ideal for panel cabinet installation in limited spaces. The shell adopts a professional protective design, adapting to strong light and wide viewing angle environments on industrial sites with strong durability.

_____________________________________________________________________________________________________________

4. Structure and Components

• Display Unit: Fitted with a 3.5-inch LCD screen, delivering clear graphical and numerical displays of various electrical parameters, allowing users to intuitively view real-time operating data.
• Measurement Unit: Internally integrated with high-precision current transformers and voltage transformers, responsible for accurately collecting electrical parameters and laying a solid foundation for precise measurement.
• Communication Module: Includes a Modbus RS485 interface card, supporting fieldbus communication to realize stable data transmission between the meter and upper-level systems, realizing remote monitoring and control.
• Relay/Input Module: Comprises 4 groups of digital inputs (DI) for external signal collection and 2 groups of relay outputs (RO) for external equipment control, expanding the meter’s application scenarios in system linkage.
• Power Module: Built-in power management system with a wide voltage input range, ensuring stable power supply for the meter even in complex power supply environments, supporting long-term reliable operation.

_____________________________________________________________________________________________________________

5. Application Fields

• Industrial Power Distribution Monitoring: Widely used in manufacturing workshops, automated production lines, industrial plants and other scenarios to realize real-time monitoring and management of on-site power distribution systems.
• Commercial Buildings: Applied to office buildings, shopping malls, hotels and other commercial places for energy consumption statistics, energy-saving management and operational cost control.
• Remote Monitoring & Switching: Cooperated with Schneider Altivar frequency converters or other electrical components to realize centralized control and unified management of electrical equipment.
• Power Monitoring: Used for power grid harmonic monitoring, power quality analysis and electrical parameter detection, helping to optimize power grid operation and improve power supply quality.

_____________________________________________________________________________________________________________

6. Installation and Maintenance Recommendations

• Pre-Installation Inspection: Confirm that the rated voltage of the meter matches the on-site power grid voltage, and check the wiring terminals for looseness or poor contact to avoid potential faults caused by improper connection.
• Power Supply Requirements: Ensure a stable external power supply for the meter itself; stable power input is a prerequisite for the meter’s accurate measurement and long-term stable operation.
• Communication Debugging: After connecting the Modbus cable, set the communication address and match the baud rate on the host computer or SCADA system to ensure smooth data transmission and normal system docking.
• Regular Calibration: Despite the meter’s high-precision performance, on-site calibration is recommended every 2 years in accordance with industry standards to maintain long-term metering accuracy and compliance.
• Protection Measures: When installing the meter in a panel cabinet, reserve sufficient ventilation space to prevent overheating caused by high temperature, which may affect the meter’s performance and service life.
