Schneider TSXH5744M Thermal Standby Processor
Schneider TSXH5744M
Overview
The TSXH5744M is a Hot-Standby processor from Schneider Electric’s Unity series, featuring a 1-rack design (supporting 6, 8, or 12 slots). Specifically engineered for industrial automation systems requiring high availability and reliability, this processor supports up to 4 COM modules, enabling redundant control and fast switchover. It is ideal for critical processes, continuous production lines, and other mission-critical applications.
Key Technical Specifications
| Parameter | Description |
|---|---|
| Digital I/O | 2048 points |
| Analog I/O | 256 points |
| Process Control Channels | 60 channels |
| Ethernet Ports | Up to 4 ports |
| Memory Capacity | 440 KB (without PCMCIA) / 2,048 KB (with PCMCIA) |
| Data Storage Capacity | 16 MB |
| Maximum Local Data Capacity | 64 KB |
| Instruction Execution Time | Boolean instructions: 0.039 µs; Fixed-point arithmetic instructions: 0.054 µs |
| Rack/Slot Configuration | 1 rack, supporting 6, 8, or 12-slot setups |
| COM Modules | 4 optional COM modules |
| Operating Temperature | -25 °C to +55 °C (typical) |
| Protection Class | IP20 (when installed in the rack) |
Product Features
- Hot-Standby Redundancy: Dual active/standby processors operate synchronously, with millisecond-level switchover in case of failure to ensure uninterrupted system operation.
- High I/O Density: 2048 digital I/O points and 256 analog I/O points meet the demands of large-scale on-site signal acquisition.
- Rich Communication Capabilities: Equipped with up to 4 built-in Ethernet ports, compatible with industrial protocols such as Modbus TCP, Ethernet/IP, and PROFINET.
- Expandable Storage: Memory can be expanded to 2,048 KB via PCMCIA card, with data storage up to 16 MB, suitable for complex control logic and large volumes of historical data.
- Fast Instruction Execution: 0.039 µs for Boolean operations and 0.054 µs for fixed-point arithmetic, satisfying high-speed closed-loop control requirements.
- Modular Design: 6/8/12 slots within a single rack, combined with flexible configuration of 4 COM modules, facilitating on-site wiring and maintenance.
Structure and Components
- CPU Main Unit: Core processing unit providing high-speed computation and real-time control.
- COM Modules (Up to 4): Used for expanding I/O, communication, or specialized functions (e.g., counting, position control).
- Power Supply Module: Delivers 24 V DC power with overload and short-circuit protection.
- Heat Dissipation Device: In-rack air cooling or forced fans ensure reliable operation in high-temperature environments.
- Rack Mounting Brackets: DIN rail or rack mounting compliant with IEC 60204-1 standards.
Typical Application Areas
- Continuous production lines (chemical, food, packaging industries)
- Critical process control (oil, gas, metallurgical industries)
- Large-scale machinery and robot control systems
- Power and energy management (distribution automation, microgrids)
- Process monitoring and data acquisition (SCADA, MES)
Installation and Maintenance Guidelines
- Rack and Power Supply: Ensure the rack complies with 1-rack (6/8/12-slot) specifications. Use 24 V DC power supply and do not exceed the rated current.
- Hot-Standby Wiring: Connect active and standby processors via a dedicated Hot-Standby Bus for clock and data synchronization.
- COM Module Insertion/Removal: Replace modules only when power is off to avoid arcing during operation.
- Heat Dissipation Inspection: Regularly clean dust from heat sinks or fans to maintain unobstructed heat dissipation channels.
- Firmware Upgrade: Use Schneider’s official Unity Pro software for firmware updates to ensure compatibility and security.
- On-Site Debugging: Utilize built-in diagnostic functions to monitor I/O status, network connectivity, and redundancy switchover time for timely anomaly detection.
————————————————————————————————————-
