1. Overview

2. Specifications

3. Product Features

• High-Performance Processing Capacity: Equipped with powerful CPU processing capability, it can handle complex control algorithms and a large number of I/O signals, suitable for large-scale system integration.
• Flexible I/O Expansion: Supports a large number of discrete and analog I/O points, meeting the diverse needs of complex industrial sites.
• Rich Communication Options: Integrates Ethernet, RS485, and PCMCIA expansion slots, supporting multiple fieldbuses and upper computer communication protocols.
• Reliable Industrial-Grade Design: Complies with strict standards for industrial automation equipment, featuring anti-interference, long service life, and high stability.
• Modular Design: Double-slot design facilitates maintenance and expansion, and the rack slots can be flexibly configured according to system requirements.

_______________________________________________________________________________________________________

4. Structure and Composition

• CPU Unit: The core computing and control unit responsible for running control logic.
• I/O Interface: Includes digital input/output (DI/DO) and analog input/output (AI/AO) terminals for connecting on-site equipment.
• Communication Module: Includes Ethernet port, RS485 serial port, and PCMCIA slot for communicating with other controllers or upper systems.
• Storage Expansion: Supports PCMCIA cards for expanding program capacity or adding additional communication interfaces.
• Power Module: Responsible for power supply and distribution to ensure stable operation of the equipment.

_______________________________________________________________________________________________________

5. Application Fields

• Petrochemical Industry: Used for controlling complex chemical processes and safety monitoring.
• Energy Management: Suitable for automatic control of large-scale energy systems such as power plants and distribution networks.
• Water Treatment: Used for precise process control in sewage treatment and water supply systems.
• Food and Beverage: Used for controlling high-speed packaging lines and automatic production lines.
• General Industrial Automation: Suitable for various automation systems that require a large number of I/O points and high-speed data processing.

_______________________________________________________________________________________________________

6. Installation and Maintenance

Installation Notes

• Ensure the installation environment meets the IP20 protection level requirements to avoid the impact of moisture or high-temperature environments.
• Wire correctly to ensure good polarity and contact of power supply, voltage, and signal lines.
• It is recommended to plug and unplug the PCMCIA card when the power is off to avoid damaging the equipment.

Maintenance Recommendations

• Regularly check the tightness of the connection terminals to prevent signal instability caused by looseness.
• Monitor the operating temperature of the CPU to ensure it operates within the rated temperature range.
• Perform regular firmware or software upgrades to obtain the latest features and security patches.
• For equipment that has been shut down for a long time, it is recommended to perform environmental cleaning and warm-up start checks.

————————————————————————————————————-
