Schneider VX4G46116 Circuit Breaker Module
Schneider VX4G46116
1. Product Overview
The VX4G46116 is a model in the VX series circuit breakers of Schneider Electric. It is mainly used in industrial and commercial power distribution systems, featuring reliable overload and short-circuit protection functions to ensure the safe and stable operation of power circuits and equipment.
_______________________________________________________________________________________________________
2. Core Specifications
|
Parameters
|
Specifications
|
|---|---|
|
Rated Current (In)
|
6A
|
|
Poles
|
1 Pole
|
|
Rated Voltage (Ue)
|
250V AC / 400V AC
|
|
Pole-to-Pole Rated Voltage (Ue1)
|
480V AC
|
|
Tripping Characteristic
|
Type C (Instantaneous Tripping Range: 5-10 Times In)
|
|
Pole-to-Pole Resistance
|
≤ 0.1 Ω
|
|
Electrical Life
|
50,000 Trips/Closures
|
|
Mechanical Life
|
1,000,000 Closures
|
|
Environmental Adaptability
|
Temperature Range: -25°C – 70°C
|
|
Protection Class
|
IP20 (Non-Waterproof and Dustproof)
|
_______________________________________________________________________________________________________
3. Product Features
- High-Precision Tripping: Adopts a plastic tripping mechanism with a tripping precision of up to 5%, ensuring accurate protection against overload and short circuit.
- Excellent Heat Resistance: Equipped with low thermal resistance silicone sleeves and gaskets, it has excellent heat dissipation performance, suitable for working conditions with high ambient temperatures.
- Compact Structure: Small overall size with a backplane width of only 100mm, facilitating high-density installation in distribution cabinets.
- Low Power Consumption: The plastic tripping mechanism ensures minimal leakage current, achieving energy saving and environmental protection.
_______________________________________________________________________________________________________
4. Structure and Composition
- Circuit Breaker Body: Includes tripping mechanism, spring mechanism and pole plate, which is the core part of the product.
- Terminals: Used to connect the wires of the circuit, adopting screw connection for firm and reliable connection.
- Backplane: Fixed in the distribution cabinet for installation and connection of the circuit breaker.
- Handle: Used for manual closing and opening of the circuit breaker, easy to operate and with clear state indication.
_______________________________________________________________________________________________________
5. Application Fields
- Power Distribution Systems: Used to protect distribution lines and equipment, preventing electrical accidents caused by overload or short circuit.
- Industrial Automation: Applied in control cabinets and distribution boxes to protect control circuits and power circuits.
- Building Power Distribution: Provides overcurrent protection in the power distribution network of commercial buildings and residential communities.
————————————————————————————————————-
