ABB SUBH1 Cozbu 110 Voltage Release Device
ABB SUBH1 Cozbu 110
Product Parameters
|
Parameter Item
|
Specification
|
|---|---|
|
Rated Control Voltage
|
110V AC/DC (Operating Range: 110-127V AC, 110-132V DC)
|
|
Frequency
|
50Hz / 60Hz
|
|
Tripping Voltage Range
|
35%-70% of Rated Voltage
|
|
Reset Voltage
|
Approx. 65%-85% of Rated Voltage
|
|
Contact Capacity
|
6A / 690V AC
|
|
Power Consumption
|
Approx. 60W (110V DC)
|
|
Protection Class
|
IP20
|
|
Operating Temperature
|
-25°C to +55°C
|
|
Installation Position
|
Left Pole Installation
|
Product Features
- Safe and Reliable: Built-in cut-off switch to protect the coil from damage caused by continuous energization.
- Fast Tripping: Reliable operation when the voltage drops to 35%-70% of the rated value.
- Tool-Free Installation: Quick snap-on installation design, no special tools required.
- Surge Protection Design: Can withstand surge voltages up to 6kV.
- Clear Marking: Clear terminal markings on the front panel for easy wiring.
- Compact Structure: 9.9(W) × 43(H) × 39.5(D) mm, saving installation space.
- Multi-Application Compatibility: Can be used with auxiliary contacts and supports testing functions.
Structure and Composition
|
COZBU 110 Structure and Composition
|
|
|---|---|
|
Coil Winding
|
Electromagnetic Tripping Mechanism
|
|
Terminal Block
|
Mechanical Latching Mechanism
|
|
Mounting Bracket
|
Reset Spring
|
|
Housing (Flame-Retardant Plastic)
|
Indicator Mechanism
|
- Coil Winding: 110V electromagnetic coil.
- Terminal Block: Screw-type terminal block with open design.
- Mechanical Mechanism: Including latch, reset spring and tripping device.
- Housing: Flame-retardant plastic material with IP20 protection.
Application Fields
- Industrial Manufacturing: Circuit breaker protection for equipment such as machine tools and production lines.
- HVAC Systems: Heating, ventilation and air conditioning control systems.
- Oil and Gas Processing: Power distribution systems in the oil and gas industry.
- Power Systems: Remote breaking control for high-voltage switchgear and distribution cabinets.
- Building Electrical: Building automation control systems.
- Wind Power Industry: Special low-voltage power distribution systems for wind power generation.
Maintenance
|
Maintenance Item
|
Cycle
|
Method
|
|---|---|---|
|
Visual Inspection
|
Quarterly
|
Check if the housing is intact and free of damage.
|
|
Wiring Inspection
|
Annually
|
Check if the terminal blocks are loose or oxidized.
|
|
Function Test
|
Annually
|
Perform tripping function test.
|
|
Cleaning
|
Annually
|
Remove dust and foreign objects.
|
Troubleshooting
|
Fault Phenomenon
|
Possible Cause
|
Solution
|
|---|---|---|
|
No Tripping
|
Excessively High Voltage
|
Check if the control voltage is within the specified range.
|
|
False Tripping
|
Excessively Low Voltage
|
Check the stability of the control power supply.
|
|
Coil Burnout
|
Continuous Energization
|
Confirm whether the internal cut-off switch is installed.
|
|
Mechanical Jamming
|
Foreign Object Entry
|
Clean the internal mechanism.
|
————————————————————————————————————-
