TRICONEX 3604E

The TRICONEX 3604E is a digital output module specifically designed for Safety Instrumented Systems (SIS), featuring a Triple Modular Redundancy (TMR) architecture to ensure continuous operation even in the event of a single component failure.

This module primarily converts digital signals from control systems into control signals to drive field actuators such as relays, solenoid valves, and more. It supports multiple communication protocols (e.g., Modbus, DNP3, OPC) and complies with SIL 2 and SIL 3 certification standards.

-

Specifications

• Output Points: 16 digital output channels.
• Output Type: DC voltage output, with a maximum current of 2A per point and a peak current of 10A.
• Output Voltage: 24VDC, with a load voltage range of 22–45VDC.
• Response Time: Less than 1 millisecond.
• Operating Temperature Range: -40°C to 70°C or -40°C to 85°C.
• Protection Rating: IP67.
• Dimensions: 190 mm × 60 mm × 35 mm.
• Weight: 0.5 kg.

-

Key Features

• High Reliability: The TMR design ensures uninterrupted operation even if a single component fails.
• High-Density Design: Multiple independent digital output channels per module enhance system integration.
• Self-Diagnostic Function: Features fault detection and isolation, supporting online diagnostics and status indication.
• Flexible Configuration: Supports hot-swapping, minimizing downtime and simplifying maintenance.
• Industrial-Grade Design: Suitable for harsh environments, including oil & gas, power generation, and metallurgy industries.

-

Structure and Composition

• The module adopts a modular design for easy installation and maintenance.
• Internally, it contains multiple output switch driver circuits, with each channel connected to the terminal panel via a backplane and cables.
• Each output point is equipped with a status indicator to display ON/OFF state, fault, or activation status.
• Integrated reverse voltage protection prevents damage from induced reverse voltage.

-

Applications

• Process Industries: Oil & gas, power generation, metallurgy.
• Infrastructure: Water treatment, wastewater treatment.
• Other Industrial Sectors: Pharmaceuticals, food & beverage, Emergency Shutdown Systems (ESD), Burner Management Systems (BMS).
• Critical Safety Applications: Fire alarm systems, Emergency Shutdown Systems (ESD), Burner Management Systems (BMS).
