Product Overview

Core Specifications

Product Features

• High Cost-Effectiveness: As a low-cost HMI device, it balances budget constraints and quality requirements, making it a highly cost-effective solution for industrial applications.
• Compact and Durable: The eTOP05P version adopts coated electronic components, which enhances resistance to harsh industrial environments.
• Powerful Functions: Supports vector graphics, recipe memory, alarm management, event lists, password protection and other rich functions, suitable for complex control needs of industrial sites.
• Programming-Friendly: Compatible with UniOP Designer 6 software, featuring intuitive programming and support for secondary development.

___________________________________________________________________________________________________________________________

Structure and Composition

• Display Module: A 5.7-inch STN LCD at the center of the panel, providing clear text and graphics display.
• Touch Layer: A resistive touch panel covering the display screen, allowing users to interact directly through touch.
• Control Mainboard: Internally integrates a processor, memory and interface circuits, responsible for data processing and communication.
• Interface Panel: Equipped with various communication interfaces (serial port, field bus, Ethernet) and power interface on the side or back.
• Housing: Usually made of plastic or metal materials, providing basic physical protection for internal components.

___________________________________________________________________________________________________________________________

Application Fields

• Machine Tool Control: Local display and control of CNC systems.
• Process Control: Status monitoring of production lines in chemical, food, packaging and other industries.
• Building Automation: Interactive interface for HVAC systems and access control systems.
• Energy Management: Display of operating data for power stations and generator sets.

___________________________________________________________________________________________________________________________

Installation and Maintenance

Installation Recommendations

• Fixing Method: Wall-mounted or desktop installation is available. Avoid direct sunlight during installation to prevent affecting LCD readability.
• Power Connection: Usually powered by 24V DC power supply, ensuring the power voltage is stable within the range of 18V-30V.
• Environmental Adaptation: Although the protection class is only IP20, it is suitable for indoor environments without corrosive dust and water droplets.

Maintenance Points

• Regular Cleaning: Wipe the screen surface with a clean dry cloth or slightly damp soft cloth; do not use corrosive cleaning agents.
• Interface Inspection: Regularly check whether the connecting cables are loose or aging, especially when the plugging frequency is high in industrial environments.
• Firmware Update: Contact the supplier to obtain the latest firmware version as needed to solve potential compatibility issues or security vulnerabilities.

————————————————————————————————————-
