1. Overview

2. Core Specifications

3. Product Features

• High Integration: Integrates display, touch control, CPU, memory, and power management functions in a small-size panel, saving installation space effectively.
• Industrial-Grade Reliability: Equipped with a wide operating temperature range, the resistive touchscreen maintains stable performance even in harsh industrial environments.
• Multiple Communication Interfaces: Supports various serial port configurations and Ethernet, facilitating seamless integration into different fieldbuses and PLC systems.
• Low Power Consumption Design: Usually adopts 24V DC wide-voltage input, compatible with standard industrial power supplies.

___________________________________________________________________________________________________________________________

4. Structure & Composition

• Display & Touch Module: Integrates a TFT LCD screen and a resistive touch sensor, ensuring clear display and sensitive operation.
• CPU Main Control Module: Based on the ARM Cortex-A8 architecture processor chip, providing efficient data processing capabilities.
• Communication & Interface Module: Includes Ethernet interface and multiple serial communication ports for flexible connectivity.
• Power Management Module: Responsible for converting 24V DC power into low-voltage power required for internal components of the panel.
• Backlight Module: Provides adjustable brightness for the screen, adapting to different ambient light conditions.

___________________________________________________________________________________________________________________________

5. Typical Application Fields

• Packaging Machinery: Used to control operating parameters of equipment such as filling machines and labeling machines.
• Textile Equipment: Used to monitor yarn tension, loom status, and other key production indicators.
• Woodworking Machinery: Serves as the operation panel for CNC cutting machines, drilling machines, etc.
• Special Machine Tools: Used for program loading and operation monitoring of CNC machine tools.
• Logistics & Sorting: Controls conveyor belts, sorting arms, and other automated logistics equipment.

___________________________________________________________________________________________________________________________

6. Installation & Maintenance

• Mounting Location: It is recommended to install in a dry and well-ventilated place, avoiding direct sunlight or strong light reflection which may affect screen visibility.
• Environmental Requirements: Avoid high temperature, humidity, or corrosive gas environments to extend the service life of the product.
• Connection Inspection: During installation, confirm that all communication interfaces (serial ports, Ethernet) are firmly connected to ensure signal integrity and stable operation.

————————————————————————————————————-
