UniOP ETOP310

1. Specifications

Core Hardware Specifications

• Display Screen: 10.4-inch TFT Color Touch Screen
• Resolution: 640×480 Pixels (VGA Level)
• Display Color: 64K Color Support
• Brightness: 250 cd/m² with Backlight Adjustment Function
• Storage: 64 MB Internal Flash Memory
• Power Supply: 24 VDC Power Supply (Applicable Range: 18V-30V)

Environmental Adaptability

• Operating Temperature: 0°C to 50°C
• Protection Level: Front Panel IP65, Rear Panel IP20

2. Product Features

Functions & Characteristics

• Multi-Interface Support: Equipped with 10/100 Mbit Ethernet Port, USB 1.1 Host Interface, as well as RS-232, RS-485, RS-422 Serial Ports, supporting Fieldbus communication.
• Display Function: Supports vector graphics, TrueType fonts, object dynamics (hide/display), and video input function.
• Data Management: Has data acquisition, trend analysis, recipe storage, and multi-language display capabilities.
• Networking Capability: Supports UniNet network protocol and adopts client/server mode, facilitating integration into large-scale automation systems.
• Safety: Supports hardware real-time clock, screen saver, buzzer alarm, and password protection mechanism.

3. Structure & Composition

Panel Layout

• Front Panel: Includes touch screen, 4 user indicator lights and 4 system indicator lights, providing an intuitive operation interface.
• Rear Interface: From left to right, they are USB Interface, Ethernet Interface, PC/Printer Interface, PLC Interface, Auxiliary Interface and Power Interface (see details).

Accessories

• Touch Panel: 235x180mm touch panel option is available.
• Cover: Front panel cover and disposable protective film (PROT-14/PROT-20) are provided; the latter includes general protection and UV protection functions.

4. Application Fields

• Factory Automation: Used for machine status monitoring, parameter adjustment and process control.
• Building Automation: Used for interactive display of Building Management System (BMS).
• Other Control Systems: Scenarios requiring human-machine interaction such as recipe management and trend analysis.

5. Installation & Maintenance

Installation Methods

Maintenance Recommendations

• Protection: It is recommended to use a cover and protective film (PROT-14/20) in dusty or humid environments.
• Power Supply: Ensure that the power supply voltage is within the range of 18V-30V to avoid equipment instability caused by overvoltage or undervoltage.
• Cleaning: Regularly clean the screen with a dry soft cloth, and avoid using strong acid or alkaline cleaners to prevent damage to the screen coating.

————————————————————————————————————-
