UniOP eTOP507 Control Board Module
UniOP eTOP507
UniOP eTOP507 is a mid-to-high-end model in the eTOP series under EXOR (Italy). As an upgraded version of the UniOP series, it is specifically designed to meet HMI (Human-Machine Interface) requirements in harsh industrial environments. While maintaining the durability and compatibility of the UniOP series, eTOP507 introduces more powerful processing capabilities, richer network functions, and more flexible multi-language support.
_____________________________________________________________________________________________________________
2. Core Specifications
- Display: 7-inch (approximately 17.8cm) color display with a resolution of usually 800×480 pixels or higher, wide viewing angle, and high-brightness display support.
- Touch Technology: 5-wire or 10-wire Capacitive Touch screen, supporting multi-touch, with high touch sensitivity and wear resistance.
- CPU: Adopts a high-performance industrial-grade embedded processor, supporting complex graphical interfaces and fast data processing.
- Memory: Built-in 2GB DDR4 RAM, with storage space usually 4GB-8GB (EMMC or SSD), meeting the storage needs of large engineering files.
- Communication Interfaces: Equipped with multiple RS-485 interfaces (supporting protocols such as Modbus RTU/ASCII, Profibus DP, CANopen, Ethernet/IP), enabling direct connection to various PLCs (Siemens, Mitsubishi, Omron, Schneider, etc.).
- Network Functions: Supports Ethernet 10/100M (Wi-Fi module optional), with basic network diagnosis and remote access functions.
_____________________________________________________________________________________________________________
3. Product Features
- Industrial-Grade Durability: Usually reaches IP65 protection level, with dust resistance, water resistance, low-temperature resistance (-25℃) and high-temperature resistance (+60℃) capabilities.
- Multi-Language Support: Built-in multi-language library, suitable for multi-language operating environments.
- Rich Industrial Protocols: Supports various protocols such as Modbus, Profibus, and CAN, with extremely strong compatibility.
- Fast Boot: Adopts an optimized system structure, with fast boot speed and stable operation.
- Modular Design: Easy to install and maintain, supporting modular replacement.
_____________________________________________________________________________________________________________
4. Structure and Composition
- Panel Main Body: Includes LCD/LED display, touch glass layer, backlight module, and PCB main board.
- Chassis: Industrial-grade chassis, usually made of metal or high-strength plastic, with built-in protective sealing ring.
- Connection Terminal Block: DIN rail terminal block on the back panel or side panel, used for wiring PLCs and sensors.
- Power Module: Internal or external power supply module, providing stable working voltage (usually 24V DC).
_____________________________________________________________________________________________________________
5. Typical Application Areas
- Packaging Machinery: Control interfaces for food packaging, bottling, and canning machines.
- Machine Tools and Special Machines: CNC machine tools, laser cutting machines, punch presses, etc.
- Automation Transformation: Modernization transformation of old machines, replacing traditional button panels.
- Logistics Systems: Sorting equipment, conveyor belt control systems.
- Textile and Woodworking: Production line monitoring and operation.
_____________________________________________________________________________________________________________
6. Installation and Maintenance Recommendations
Installation
It is recommended to adopt DIN rail installation. Use screws or fixed brackets to fix the chassis inside the control cabinet or on the surface of the chassis, ensuring that the panel is aligned with the operator’s line of sight.
Wiring
Be sure to cut off the power before wiring. Use insulating tape or heat shrink tubing to protect the wiring terminals to avoid loosening.
Daily Maintenance
Regularly wipe the panel with a clean soft cloth, and avoid using chemical solvents. Periodically check the integrity of the chassis sealing strip to prevent dust from entering the interior. If there are scratches on the touch screen surface, it is recommended to replace the panel glass to avoid affecting touch sensitivity.
————————————————————————————————————-
