UNIOP ETOP507U3P1 Control System Power Module
UNIOP ETOP507U3P1
1. Product Overview
2. Core Technical Parameters
|
Parameters
|
Description
|
|---|---|
|
Display Size
|
5.7-inch TFT Color LCD
|
|
Resolution
|
320 × 240 Pixels (QVGA)
|
|
Display Color
|
65,536 Colors (16-bit Color)
|
|
Touch Method
|
Resistive Single-Point Touch
|
|
Communication Interfaces
|
RS232, RS485, USB Host, Ethernet (depending on specific configuration)
|
|
Protection Level
|
Front Panel IP65 (Dustproof and Waterproof)
|
|
Operating Temperature
|
0°C to +50°C
|
|
Power Input
|
24V DC (usually range 18-30V)
|
|
Operating System
|
Embedded Linux
|
|
Development Tool
|
JMobile Studio (supports IEC 61131-3 standard)
|
___________________________________________________________________________________________________________________________
3. Product Features
- Industrial-Grade Reliability: With IP65 protection level and wide temperature operating range, it is suitable for harsh industrial environments.
- Strong Compatibility: Supports various PLCs and industrial protocols (such as Modbus, Profibus), facilitating integration with existing systems.
- Easy Development: The supporting JMobile Studio software allows interface design and logic programming using IEC 61131-3 programming languages (such as Structured Text, Function Block Diagram).
- Multi-Functional Interfaces: In addition to common serial communication, some models also support multiple interfaces such as Ethernet, CAN, and USB.
___________________________________________________________________________________________________________________________
4. Structure and Composition
- TFT Color Screen Module: Responsible for displaying graphical interfaces and operation feedback.
- Touch Layer: Resistive touch panel, responsible for sensing user input.
- Control Motherboard: Built-in microprocessor (usually ARM architecture) and embedded software running Linux system.
- Communication Module: Provides interfaces such as RS232/RS485/Ethernet for communication with PLC or upper computer.
- Power Module: Converts external 24V DC voltage into the working voltage required internally.
___________________________________________________________________________________________________________________________
5. Typical Application Fields
- Mechanical Equipment Control: Such as textile machinery, packaging machinery, woodworking machinery, etc.
- Automated Production Lines: Used for monitoring production status, parameter setting and fault diagnosis.
- Process Control: Cooperate with PLC for display and control of process data.
- Instrument Display: Used for displaying sensor data, graphical trends, etc.
___________________________________________________________________________________________________________________________
6. Installation and Maintenance Recommendations
Installation Recommendations
- Ensure the installation location meets the requirements of IP65 protection level, and avoid direct exposure to strong water flow or dust environment.
- Correctly connect the 24V DC power supply, and check the power polarity to prevent damage to the equipment.
- Correctly connect the communication cables (such as RS485 using differential signals) to avoid communication failures caused by wrong wiring.
Maintenance Points
- Regularly clean the front panel, keep the touch screen surface dry and clean, and avoid oil stains affecting touch sensitivity.
- Check the connection status of power supply and communication interfaces to prevent false alarms or disconnections caused by looseness.
- Pay attention to anti-static operations when replacing or maintaining to avoid damage to internal circuits.
————————————————————————————————————-
