Yaskawa CIMR-PW4A0208A AA Drive Module
Yaskawa CIMR-PW4A0208A
The CIMR-PW4A0208AA is a dedicated pump drive (iQpump1000) belonging to Yaskawa’s A1000 series, engineered for high-power industrial pumping systems such as 150 HP (approx. 112 kW) centrifugal pumps and positive displacement pumps. It accepts a 380–480 V three-phase input and delivers an output current of 208 A, housed in a standard enclosed cabinet that is ideal for harsh industrial environments. Integrated with pump-specific functions including soft start, soft stop, and torque limiting, this drive ensures efficient and stable control of pump operations.
Key Technical Specifications
| Parameter | Details |
|---|---|
| Rated Power | 150 HP (≈ 112 kW) |
| Input Voltage | 380–480 V three-phase, 50/60 Hz |
| Output Current | 208 A (standard mode) |
| Rated Torque | 208 Nm (standard torque) |
| Rated Speed | 0–1800 r/min (configurable) |
| Power Factor | ≥ 0.95 (high power factor) |
| Efficiency | ≥ 96 % (high-efficiency design of A1000 series) |
| Environmental Rating | IP20 (standard cabinet); IP54 enclosure optional |
| Cooling Method | Forced air cooling via internal fan; fan field-replaceable |
| Communication Interfaces | Multiple fieldbuses including Modbus RTU, Ethernet/IP, PROFINET, CANopen |
| Control Mode | Vector control (V/F, FOC), supporting soft start/stop, torque limiting, and pump characteristic curve mapping |
| Dimensions/Weight | Approx. 450 mm × 350 mm × 250 mm; approx. 30 kg |
Product Features
- Pump-Specific Functions
Built-in pump characteristic curves (H-Q, N-Q) enable automatic flow/pressure control, preventing pump idling and hydraulic shock.
- High Energy Efficiency
The A1000 series adopts advanced power semiconductors and vector control algorithms, achieving up to 96% efficiency and significantly reducing operational electricity costs.
- Multi-Protocol Communication Compatibility
Compatible with mainstream industrial networks, it allows seamless integration into SCADA, MES, or upper-level control systems.
- Enhanced Reliability
Equipped with high-reliability power modules and protection mechanisms against overheating, overcurrent, and overvoltage. Complies with IEC 61800-5-1 standards.
- Easy Maintenance
Modular PCB design allows field replacement of key components (e.g., fans, power modules), minimizing system downtime.
- Flexible Installation Options
Offers standard cabinet, IP54-protected enclosure, and optional explosion-proof housing to meet diverse on-site requirements.
Structure and Components
- Main Cabinet
Houses power modules, control PCBs, and cooling fans, providing overall mechanical support.
- Control PCB (A1000 Series)
Manages vector control algorithms, parameter storage, and communication interface operations.
- Power Module
Utilizes IGBT/IGCT high-power semiconductors to deliver high-frequency PWM output.
- I/O Terminal Board
Provides analog/digital input/output ports and fieldbus connection terminals.
- Power Supply Module
Internal auxiliary power supply for powering the control circuit.
- Heat Dissipation System
High-efficiency fan plus heat sink; fan is field-replaceable for easy maintenance.
- Optional Braking Unit
Delivers braking functionality for pump loads requiring rapid stop.
Typical Application Fields
- Petrochemical Industry: Crude oil and refined oil transfer pumping stations.
- Water Treatment: Water supply, sewage lift pumps, and circulation pumps.
- Power/Energy Sector: Boiler feedwater pumps, condensate pumps, and gas circulation pumps.
- Mining Industry: Slurry pumps and drainage pumps.
- Paper and Packaging Industry: Pulp transfer and liquid conveying systems in packaging lines.
- Others: Industrial pump systems requiring high flow and constant pressure control in food processing, pharmaceuticals, textiles, and more.
