Yaskawa SGMKS-44A5A-MU13 AC Servo Motor
Yaskawa SGMKS-44A5A-MU13
The SGMKS‑44A5A‑MU13 is a 4.4 kW (approx. 6 HP) AC servo motor launched by YASKAWA to meet the mid-to-high power requirements of industrial automation. As a member of YASKAWA‘s X Series servo motors, it adopts a high-efficiency permanent magnet synchronous rotor and can be equipped with optional encoders or brakes, making it specially designed for high-speed, high-precision motion control applications. This model is widely used in domestic and international industrial equipment, including CNC machine tools, packaging machinery, injection molding machines, and printing equipment.
Key Technical Specifications
| Parameter | Typical Value | Description |
|---|---|---|
| Rated Power | 4.4 kW (≈ 6 HP) | Suitable for high-speed motion under medium loads |
| Rated Speed | 3000 r/min (0–3000 r/min optional) | Wide-range speed regulation via variable frequency drive |
| Rated Torque | Approx. 12 Nm (varies with specific configuration) | Continuous torque matched to rated power |
| Peak Torque | Approx. 30 Nm (≈ 2.5 times the rated torque) | Delivers instantaneous power for acceleration or shock load conditions |
| Motor Dimensions | Flange 44 mm × 5 mm (indicated by “44A5A” in model number) | Standardized flange for easy mechanical assembly |
| Encoder | Optional 1000 ppr, 2000 ppr, or 5000 ppr incremental encoders | Supports closed-loop position/speed control |
| Brake | Optional built-in brake (MU13 indicates brake-free version) | External brakes can be fitted if required |
| Rated Voltage | 200 V–240 V AC three-phase | Compatible with YASKAWA inverters (Sigma‑7, Sigma‑5 series) |
| Insulation Class | Class F (temperature resistance up to 105 °C) | Ideal for conventional industrial environments |
| Protection Class | IP54 (dust-proof and splash-proof) | Suitable for workshop and semi-enclosed settings |
| Weight | Approx. 12 kg | Easy to handle and install |
Product Features
-
High Power DensityWith a rated power of 4.4 kW packed into a 44 mm flange size, the motor features a compact footprint and lightweight design, enabling easy installation in space-constrained mechanical structures.
-
High Efficiency & Low Heat GenerationThe permanent magnet synchronous rotor integrated with advanced vector control technology achieves an efficiency of over 92%. It operates with low temperature rise, reducing the need for additional cooling systems.
-
Multiple Encoder OptionsSupports 1000–5000 ppr incremental encoders, catering to diverse requirements ranging from basic positioning tasks to high-resolution servo control applications.
-
Optional Brake ConfigurationThe standard model (MU13) is brake-free, but built-in brakes can be customized according to system safety requirements to enhance shutdown reliability.
-
Full Compatibility with YASKAWA Servo DrivesSeamlessly pairs with Sigma‑7, Sigma‑5, Sigma‑3 and other YASKAWA drives, supporting multiple control modes (position, speed, torque).
-
Modular Maintenance DesignEquipped with a detachable terminal board and standardized flange, the motor allows for quick on-site replacement or repair, minimizing equipment downtime.
Structure & Components
- Rotor: Permanent magnet synchronous rotor made of high-energy magnetic materials, delivering strong torque output.
- Stator: Three-phase windings wound with high-conductivity copper wire and insulated to meet Class F temperature resistance standards.
- Flange: 44 mm × 5 mm standard flange with pre-drilled bolt holes for convenient mechanical connection.
- Encoder Mount: Optional mounting for incremental encoders, available in coaxial or side-mounted configurations.
- Terminal Box: Detachable terminal board providing connection points for three-phase power, grounding, and encoder signals.
- Heat Sink/Fan (Optional): Forced air cooling can be added for operation under high-load or high-ambient temperature conditions.
Typical Application Fields
- CNC machine tools (turning, milling, grinding)
- Injection molding & die-casting machines (high-speed feeding, precision positioning)
- Packaging & printing machinery (high-speed winding, paper conveying)
- Automated assembly lines (robot joints, transfer arms)
- Textile & leather machinery (tension control, synchronous driving)
- Semiconductor & precision processing equipment (fine-tuning positioning, low-inertia systems)
————————————————————————————————————-
