Yaskawa UAASD-30WMU11

The UAASD-30WMU11 is a high-performance AC servo reducer launched by Yaskawa Electric, engineered for industrial automation systems requiring high precision and compact configurations. As a member of the UAASD series, this model is specifically designed for medium-to-low power (30 kW) applications, delivering a superior combination of high torque output and low-noise operation.

Main Technical Specifications

• Rated Power: 30 kW (approx. 40 HP)
• Rated Speed: 3000 r/min (motor side)
• Output Speed Range: 30–300 r/min (available gear ratios: 10:1, 15:1, 20:1)
• Maximum Output Torque: Approx. 300 Nm (varies by gear ratio)
• Efficiency: ≥ 92% (under rated operating conditions)
• Operating Temperature: -20 °C to +60 °C
• Protection Class: IP65 (dustproof and waterproof)
• Control Interface: Supports fieldbuses including EtherCAT, PROFINET and CANopen; compatible with Yaskawa’s proprietary Motion-Net controllers

Product Features

1. High Precision & Low Backlash


   Adopts Yaskawa’s patented harmonic drive mechanism, with backlash less than 3 arc-min and positioning error ≤ ±0.02 mm.

2. Compact & Lightweight


   The overall volume is about 30% smaller and weight is reduced by around 25% compared with traditional planetary reducers of the same power rating.

3. High Efficiency


   Minimal energy loss during deceleration translates to significantly lower operational costs.

4. Multi-Protocol Compatibility


   Plug-and-play design enables seamless integration with existing automation platforms.

5. High Reliability


   Built with high-strength alloy gears and high-temperature lubricating oil, boasting a designed service life of ≥ 200,000 hours.

Structure & Components

• Motor Body: Permanent magnet synchronous motor equipped with high-efficiency heat sinks.
• Harmonic Drive Unit: Comprises three core components: wave generator, flexspline and circular spline.
• Control Cabinet: Integrated with driver, power module, communication interfaces and safety protection circuits.
• Cooling System: Air-cooled or water-cooled options, selectable based on on-site requirements.
• Mounting Bracket: Standardized flange, supporting both flange-mounted and base-mounted installation.

Typical Application Fields

• Robot Joints: Collaborative robots, 6-axis industrial robots
• Packaging Machinery: High-speed packaging, cartoning and palletizing equipment
• Printing & Textile: Tension control for high-speed printing machines and textile machinery
• Semiconductor & Precision Machining: Precision positioning for lithography machines and CNC machine tools
• Automated Assembly Lines: Transfer arms, dispensing machines and testing equipment

Installation & Maintenance Guidelines

1. Pre-Installation Inspection


   Verify matching of flange dimensions, bolt specifications and power supply voltage.

2. Alignment & Fixation


   Use a level to ensure the base is horizontal; tighten bolts according to the torque values specified in the technical manual.

3. Electrical Wiring


   Comply with IEC 60204-1 standard and ensure the power supply is disconnected before wiring.

4. Lubrication Maintenance


   Check and replenish the lubricant level within 500 hours of initial operation; replace the lubricant every 2000 hours thereafter.

5. Temperature Monitoring


   Monitor the temperature of the motor and drive unit during operation; inspect the cooling system if the temperature exceeds the rated limit.

6. Troubleshooting


   Built-in self-test functions and fieldbus alarm messages enable quick identification of issues such as bearing wear and abnormal gear meshing.
