Yaskawa SGMVH-5ZDXB-YG11

1. Overview

2. Key Specifications

3. Product Features

• High Power Density: With an output of 50 kW, it has a relatively high power density among similar products, making it suitable for space-constrained applications.
• High Torque: The rated torque of 238 Nm ensures stable operation during startup and load changes.
• Reliability: Manufactured in Japan, it uses high-quality materials and strict quality control, resulting in a long service life and low failure rate.
• Multiple Cooling Options: Air-cooled or water-cooled options are available to meet different heat dissipation needs.
• Strong Compatibility: It supports standard three-phase power supplies and can be easily integrated with existing drive systems.
• Easy Maintenance: Adopting a modular design, key components (such as bearings and seals) can be replaced quickly.

4. Structure and Composition

• Stator and Rotor: Equipped with a high-efficiency magnetic circuit design to provide stable electromagnetic torque.
• Bearing System: Uses high-precision rolling bearings to reduce friction and noise.
• Cooling System: Incorporates fans or water-cooled pipelines to ensure temperature control during long-term high-load operation.
• Sealed and Protective Enclosure: Features an IP54 protection class, providing dust and water protection.
• Terminal Box: Adopts standardized wiring for easy on-site wiring.
• Mounting Base: Reserved bolt holes for stable installation.

5. Typical Application Fields

• Large CNC Machine Tools: Meeting the high-power requirements of spindle drives.
• Robot Joint Drives: The high torque ensures fast and precise movement.
• Packaging and Printing Machinery: Suitable for transmission systems that require continuous high power.
• Industrial Automation Production Lines: Applied in heavy-load equipment such as conveyors and hoists.
• Energy and Power Generation Systems: Used as backup or grid-connected generator sets.

6. Installation Points

1. Stable Foundation: Ensure the machine base is level and rigid to prevent resonance.
2. Power Supply Matching: Check that the phase sequence, frequency, and rated voltage of the three-phase power supply are consistent.
3. Cooling System Connection: If water cooling is adopted, ensure the cooling pipelines are sealed and free of leakage.
4. Wiring Inspection: Use dedicated terminals to ensure correct phase sequence and reliable contact.
5. Commissioning: Conduct an idle operation check before power-on to confirm there is no abnormal noise or vibration from the rotor.

7. Maintenance and Upkeep

• Regularly inspect bearings: Check the lubricating oil or grease every 6 to 12 months and replace if necessary.
• Clean heat dissipation devices: Dust accumulation on fans or heat sinks will affect heat dissipation, so regular dust removal is required.
• Inspect seals: Check if the outer shell seals are aging to prevent water and dust ingress.
• Electrical inspection: Regularly measure the insulation resistance to ensure no loose wiring.
• Record operating parameters: Monitor key indicators such as temperature, vibration, and power to detect abnormalities in a timely manner.

————————————————————————————————————-
