Yaskawa UAASWH-30SMU14 Servo Spindle Motor
Yaskawa UAASWH-30SMU14
The UAASWH‑30SMU14 is a high-performance servo spindle motor manufactured by Yaskawa, engineered specifically for industrial machining and automation equipment requiring high speed and high torque. Adopting a permanent magnet synchronous structure, it delivers a continuous power of 15 kW and a peak power of 22 kW with a rated input voltage of 200 V, boasting a maximum rotational speed of 15,000 rpm. This motor is ideal for applications demanding high-speed rotation, such as CNC machine tools, packaging machinery, and printing equipment.
Key Specifications (Main Technical Parameters)
| Parameter | Value | Description |
|---|---|---|
| Rated Continuous Power | 15 kW | Sustained operating power |
| Peak Power | 22 kW | Maximum short-term output |
| Rated Input Voltage | 200 V (3-phase) | Compatible with standard industrial power supplies |
| Maximum Rotational Speed | 15,000 rpm | Meets high-speed machining requirements |
| Speed Range | 4,000 - 15,000 rpm | Adjustable range for versatile process adaptation |
| Rated Torque | Approx. 135 N·m (97 N·m peak) | Nominal value referenced from eBay listings |
| Phase Configuration | 3-phase | Standard AC drive compatibility |
| Place of Manufacture | Japan | Origin assurance for quality |
| Dimensions | Standard 30 mm shaft diameter (indicated by “30″ in model name) | Compatible with same-series servo motors |
| Cooling Method | Air-cooled or water-cooled (optional) | Selectable based on actual load conditions |
Product Features
- High Speed & High Torque: With a maximum speed of 15,000 rpm and continuous power of 15 kW, it fulfills the requirements of high-speed machining and precision positioning.
- Efficient Permanent Magnet Synchronous Structure: Reduces energy consumption and improves response speed.
- Wide Speed Adjustment Range: The adjustable speed range of 4,000 - 15,000 rpm enables flexible adaptation to diverse production processes.
- Reliability: Manufactured in Japan with Yaskawa’s proven production technology, ensuring industrial-grade durability.
- Strong Compatibility: Seamlessly integrates with Yaskawa servo drives (e.g., Σ‑7 and Σ‑9 series) as well as standard PLC/motion control systems.
- Dual Cooling Options: Optional air-cooled or water-cooled systems for operation under high-load or high-temperature environments.
Structure & Components
- Permanent Magnet Rotor: Built-in high-energy permanent magnets generate strong magnetic fields.
- Stator Windings: 3-phase copper wire windings work with inverters to achieve precise torque control.
- Bearing System: High-precision rolling bearings support stable high-speed operation.
- Housing: Aluminum alloy or steel construction provides mechanical strength and heat dissipation channels.
- Connection Terminals: Standard 3-phase power terminals and encoder/feedback interfaces (with optional upgrades).
- Cooling Channels: Fan or water-cooling pipelines (depending on specific configuration).
Typical Application Fields
- CNC machine tools (milling machines, lathes, grinders)
- High-speed packaging and printing machinery
- Automated assembly lines (high-speed rotary assembly, thread machining)
- Textile and fiber processing (high-speed spinning, winding)
- Aerospace component manufacturing (precision drilling, grinding)
- Robot joints or end-effectors (joints requiring high-speed rotation)
————————————————————————————————————-
