Yaskawa UAWB-30BMU12 Servo Series
Yaskawa UAWB-30BMU12
The UAWB-30BMU12 is an AC spindle servo motor launched by Yaskawa, belonging to the high-power servo product line. It is widely used in CNC machine tools, machining centers, and automated equipment requiring high-speed and high-precision rotation. With reliable performance, a compact structure, and multiple control interfaces, this model has become a preferred choice in the industrial automation sector.
Key Technical Specifications
- Rated Power: 15 kW
- Rated Current: 147 A / 113 A (depending on operating voltage)
- Operating Voltage: 200 V (common power supply specification)
- Speed Range: 0–30,000 rpm (the “30″ in the model number indicates a maximum speed of approximately 30 k rpm)
- Shaft Diameter: Standard 30 mm (compatible with most machine tool spindles)
- Cooling Method: Built-in air cooling or water cooling
- Control Method: Compatible with Yaskawa servo drives (e.g., Σ-7, Σ-5 series) and supports multi-axis synchronous control
Product Features
- High Power Density
Delivers 15 kW output in a compact form factor, ideal for space-constrained machine tool configurations.
- Wide Speed Range
Enables smooth switching from low-speed high-torque to high-speed low-torque operation, meeting diverse processing requirements.
- High Precision & Fast Response
Adopts Yaskawa’s self-developed high-efficiency permanent magnet synchronous motor (PMSM) and advanced vector control technology, achieving ±0.02 mm positioning accuracy and rapid dynamic response.
- Robust & Reliable Design
Features a high-strength aluminum alloy housing, high-temperature resistant insulation materials, and a dustproof sealed structure, suitable for harsh industrial environments.
- Easy Integration
Equipped with standardized terminal blocks and communication interfaces (EtherCAT, PROFINET, etc.), facilitating quick connection with PLCs and CNC systems.
Structure & Components
- Motor Body: Permanent magnet synchronous rotor + high-efficiency stator windings; aluminum alloy housing for optimal heat dissipation.
- Bearing System: High-precision ball bearings provide low-friction, long-service-life rotational support.
- Cooling System: Internal fan or optional water-cooling kit ensures temperature remains within a safe range during full-load operation.
- Encoder: Built-in high-resolution incremental or absolute encoder (optional) for closed-loop position feedback.
- Terminal Block: Protective junction box with three types of connection ports for power supply, control signals, and encoders.
- Protective Housing: IP54 dustproof and waterproof rating, suitable for workshop and semi-dusty environments.
Typical Application Fields
- CNC machine tools (lathes, milling machines, drilling machines)
- High-speed machining centers (high-speed cutting, micro-machining)
- Automated assembly lines (rotary positioning, handling robots)
- Precision instruments (optical processing, semiconductor equipment)
- Packaging machinery (high-speed winding, sorting systems)
Installation & Maintenance Guidelines
Pre-Installation Inspection
- Verify that the power supply voltage matches the motor specifications and the grounding is secure.
- Check the bearing lubrication status.
- Ensure the cooling system (fan or water cooling) is unobstructed.
Mechanical Alignment
- Use locating pins or keyways to precisely align the motor shaft with the machine tool spindle to prevent axial impact.
Electrical Wiring
- Follow the wiring diagram provided by Yaskawa. Distinguish between power cables, drive signal cables, and encoder cables. Use protective terminals to avoid miswiring.
Commissioning Procedures
- Conduct a no-load speed test first to confirm that the speed range matches the rated power.
- Perform closed-loop commissioning under load, and inspect temperature rise, vibration, and noise levels.
