1. Overview

2. Specifications

• Power Range: Usually 3 HP (approximately 2.2 kW)
• Rated Voltage: Supports 230/460 VAC (specific voltage depends on wiring configuration)
• Frequency Range: 0.5 Hz – 400 Hz (high-speed mode)
• Control Modes: Supports multiple control modes (V/F, vector control, etc.)
• Enclosure Type: EOD (Extended Open Drip-proof), compliant with open drip-proof protection level, suitable for industrial environments
• Logic Interface: L3 (usually refers to a specific communication or logic input/output configuration)
• Communication Options: Optional DeviceNet (CN2) or other fieldbus modules for networked control

___________________________________________________________________________________________________

3. Product Features

• High Reliability: The 1336 series drives are renowned for their ruggedness and durability, capable of stable operation in harsh industrial environments
• Flexible Installation Methods: The EOD enclosure design allows the drive to be directly installed on the machine side or inside the cabinet, saving space
• Multiple Communication Interfaces: Supports optional communication modules such as DeviceNet and EtherNet/IP, facilitating networked linkage with PLCs
• Standardized Modularity: Excellent compatibility with other Allen-Bradley series modules (such as I/O modules and circuit breakers), enabling easy system expansion

___________________________________________________________________________________________________

4. Structure and Composition

• Drive Unit: The core circuit board, including power modules and control boards, responsible for actual power conversion and control calculations
• Logic/Communications Board: Used to process external logic signals (such as emergency stop) and network communication signals
• Terminal Block: For connecting power cables, three-phase output cables, and control cables (such as 0-10V, pulse output, etc.)
• Mounting Brackets/Bolts: EOD models are usually equipped with bracket holes or bolt holes for fixing on the machine frame

___________________________________________________________________________________________________

5. Application Areas

• Manufacturing Automation: Motor drive for production lines such as automotive assembly lines, electronic manufacturing, and food packaging
• Mechanical Equipment: Used to control the transmission systems of various machinery, such as conveyors, presses, injection molding machines, etc.
• Process Control: In industries such as petrochemicals and energy, used to control process equipment such as pumps and fans
• Building and Transportation: Suitable for motor drives in large air conditioning systems, building automation, and rail transit systems

___________________________________________________________________________________________________

6. Installation and Maintenance

Installation

• Environmental Requirements: EOD models are suitable for open cabinet or direct rack mounting, ensuring sufficient heat dissipation space
• Wiring: During installation, attention should be paid to the correct connection of power cables, three-phase output cables, and control cables. Professional electrical engineers are usually required to confirm the wiring
• Fixing Method: Usually directly fixed on the rack or machine frame with bolts, and the installation gap must comply with safety standards

Maintenance

• Daily Inspection: Regularly check for dust accumulation on the enclosure, loose terminal blocks, and aging cables
• Fault Diagnosis: Drives are usually equipped with status indicators (such as green running lights and red fault lights). Faults can be quickly located through LED indicators and PLC alarms
• Firmware Update: When necessary, firmware updates or parameter adjustments can be performed using special programming tools (such as RSLogix or Studio 5000)

————————————————————————————————————-
