1. Overview

2. Specifications

• Model: 168679-01-01-01-02-00-01
• Weight: Approximately 0.55 kg
• Manufacturer: Bently Nevada

______________________________________________________________________________________________

3. Product Features

• Stable Power Supply: Provides continuous and reliable power output to ensure 24/7 uninterrupted operation of the monitoring system.
• Modular Design: As a module of the rack system, it facilitates quick installation and replacement.
• Strong Compatibility: Suitable for various rack and module combinations of the Bently Nevada 3500/3505 series.
• Easy Maintenance: Standardized connection interfaces and structural design make on-site maintenance and troubleshooting more convenient.

______________________________________________________________________________________________

4. Structure and Composition

• Housing: Made of metal, providing mechanical protection and electromagnetic shielding.
• Power Input Interface: Used to connect external power cables (usually three-phase or single-phase electricity).
• Output Connection Terminals: Distribute power to each monitoring module on the rack (such as vibration sensor modules, temperature modules, etc.).
• Mounting Holes: Equipped with standardized screw holes for easy fixation on the rack.

______________________________________________________________________________________________

5. Application Fields

• Industrial Manufacturing: Suitable for monitoring production line equipment in factory workshops.
• Petrochemical Industry: Monitors the operating status of key equipment such as compressors, pumps, and generators.
• Power Plants: Provides continuous operation monitoring for generator sets.
• Mining and Metallurgy: Monitors the vibration and temperature of heavy-duty equipment.

______________________________________________________________________________________________

6. Installation and Maintenance

Installation Guide

1. Preparation: Ensure the rack is placed flat and stable, and confirm that the installation direction of the power module matches the rack’s guide rails.
2. Fixed Installation: Use the screws provided with the module (such as screw No. 04300111) to fix the power module at the bottom or side of the rack.
3. Power Connection: Connect the power input connector (such as 128085-01) to the external power cable and check the firmness of the wiring.
4. Connectivity Check: Ensure the power module is correctly connected to other modules on the rack (such as sensor modules) through the rack guide rails.

Maintenance and Inspection

1. Regular Inspection: It is recommended to check the power cable interface for looseness or corrosion every 6 months.
2. Troubleshooting: If the system alarms indicating a power failure, first check if the power input is normal, then check if the fuse or fuse box inside the module is blown.
3. Spare Part Replacement: If the power module itself is damaged (such as internal circuit board failure), it is usually necessary to replace the entire module instead of repairing it separately.
