Allen-Bradley 2198-S263-ERS3 Servo Drive
Allen-Bradley 2198-S263-ERS3 Product Information
1. Product Overview
- Category: Allen-Bradley 2198-S263-ERS3 EtherNet/IP Servo Drive
- Applicable Platforms: Allen‑Bradley series PLCs such as CompactLogix, ControlLogix, and Micro800
- Main Functions: Provides high-speed and precise motor position, speed, and torque control, and supports multi-axis synchronization and motion commands.
2. Key Technical Specifications
| Specification | Typical Value / Value Range |
|---|---|
| Rated Power Supply | 240 V / 480 V three-phase, 50/60 Hz |
| Rated Power | 2 kW ~ 15 kW (selected based on the rated power of specific motors) |
| Output Current | Up to 30 A (depending on power rating) |
| Control Method | EtherNet/IP (CIP)
Supports protocols such as SLC 500, PLC‑5, and Micro800 |
| Feedback Type | Encoder (incremental/absolute)
Optional magnetic encoder or optical encoder |
| Protection Class | IP20 (for indoor installation) |
| Operating Temperature | 0 °C ~ 55 °C |
| Dimensions | Standard 2U rack-mount (approximately 86 mm × 89 mm × 178 mm) |
| Weight | Approximately 2.5 kg |
3. Product Features
- High-Bandwidth, Low-Latency Communication: Adopts the EtherNet/IP CIP protocol, supporting cycle times of over 125 µs for high-speed motion control.
- Multi-Axis Synchronization: Enables synchronous control of multiple drives via the same bus, suitable for multi-axis systems such as robots and CNC machine tools.
- Modular Design: Features a standard 2U rack-mount structure, facilitating unified wiring and maintenance in cabinets.
- Rich Diagnostic Functions: Built-in fault codes, real-time status monitoring, and alarm logs to help quickly locate issues.
- Flexible Feedback Options: Compatible with multiple encoder types to meet different precision requirements.
- Safety Functions: Supports safety I/O and Safety‑Enabled network configurations, and can be integrated into safety control systems.
4. Structure and Composition
- Power Module: Responsible for AC-DC conversion and providing an internal DC bus.
- Power Module: Contains IGBT/IGBT-MOSFET power devices to realize motor drive.
- Control Processor: Runs the EtherNet/IP protocol stack and motion control algorithms.
- Communication Interface: EtherNet/IP RJ45 interface (with optional modular expansion).
- Heat Dissipation System: Internal fans and heat sinks ensure thermal balance under rated power.
- Terminal Blocks: Terminal blocks for motor phase wires, encoder signals, grounding, and power supply.
5. Typical Application Fields
| Industry | Application Examples |
|---|---|
| Automated Production Lines | Robot joint drive, conveyor belt speed control |
| CNC Machine Tools | High-precision positioning of spindles and linear axes |
| Packaging Machinery | Synchronous motion of rotating packaging heads and sorting arms |
| Plastic Injection Molding | Precise control of injection screws and mold opening/closing |
| Textile Machinery | Yarn tension control, loom drive |
| Food and Beverage | Silo conveying, fast response of filling valves |
————————————————————————————————————-
