Product Information for Allen-Bradley 5069-L350ERMS2

Key Technical Specifications

Product Features

• Coexistence of Safety and Standard Functions: The controller can run both standard tasks and SIL 2 safety tasks, simplifying the system structure.
• High-Density Motion Control: It supports synchronized motion of up to 24 axes, making it suitable for high-speed applications such as robotics and packaging lines.
• Dual-Port Ethernet: Provides redundancy and bandwidth to meet the requirements of large-scale EtherNet/IP networks.
• Modular I/O: Equipped with 31 local I/O channels, allowing flexible expansion of on-site I/O modules.
• Strong Compatibility: Fully compatible with CompactLogix 5380, Compact GuardLogix 5380, and Studio 5000, facilitating upgrades of existing systems.

Structure and Composition

• CPU Module: The core processing unit integrates dual Ethernet ports, a USB client, and a built-in safety processor.
• Memory Card Slot: Supports 1784-SD1 (1 GB) or 1784-SD2 (2 GB) memory cards for program backup and expansion.
• Optional Power Supply Module: Provides 18-32 V DC power and supports battery backup to enhance reliability.
• I/O Expansion Slot: Used for inserting local digital/analog I/O modules, with a maximum of 31 channels.

Typical Application Areas

• High-speed packaging and sorting systems
• Robotics and multi-axis motion platforms
• Injection molding and die-casting production lines
• Automotive manufacturing assembly lines
• Continuous production in food and beverage processing

Installation Points

• Chassis and Heat Dissipation: Install in a chassis compliant with IEC 60068-2-1/2 standards, ensuring ventilation or forced air cooling.
• Power Wiring: Use an 18-32 V DC power supply and follow grounding and lightning protection specifications. If battery backup is required, connect the battery module according to the manual.
• Ethernet Wiring: For dual ports, a ring or star topology is recommended to achieve redundancy. Use Cat 5e/6 or higher-grade cables.
• I/O Module Installation: First install the local I/O modules, then insert the CPU, and ensure the module latches are in place.
• Safety Configuration: Enable SIL 2 safety tasks in Studio 5000, configure safety inputs/outputs, and perform safety verification.

Maintenance Recommendations

• Regular Inspection: Check the connection status of the power supply, battery, cooling fan, and Ethernet ports every 6 months.
• Firmware Upgrade: Download the latest firmware from the official Rockwell Automation website and upgrade using Studio 5000 to obtain security patches and function enhancements.
• Program Backup: Use the built-in SD card or network backup function to save project files regularly and prevent accidental data loss.
• Environmental Monitoring: Monitor the temperature and humidity inside the chassis to ensure the working environment is within the specified range and avoid hardware failures caused by abnormal temperature or humidity.

————————————————————————————————————-
