Lam Research 810-048219-015

Product Overview

The Lam Research 810-048219-015 is a specialized Pulse Sample & Hold PCB Assembly designed for semiconductor manufacturing equipment. Parts references identify the board as “PCB ASSY, PULSE SMPL & HOLD W/ SYNC OUT,” while other equipment inventories describe it as a PCBA Pulse and Hold with Sync Out.

The board is part of the electronic control architecture used in Lam Research equipment. Its sample-and-hold and synchronization functions make it suitable for systems that need to capture, retain, and coordinate pulse-related signals during equipment operation.

Identification

• Manufacturer: Lam Research
• Part Number: 810-048219-015
• Component Type: PCB Assembly
• Functional Description: Pulse Sample & Hold with Sync Out
• Board Category: Control / signal-processing PCBA
• Application: Semiconductor manufacturing equipment
• Known Revision: Rev C is documented in current spare-parts listings
• Weight Reference: Approximately 0.25 kg according to an equipment-parts listing; actual shipping weight may vary with packaging.

Pulse Sample and Hold Function

Sample-and-hold circuitry is commonly used when an electronic system needs to capture the value or state of a signal at a specific moment and maintain that information for subsequent processing.

For semiconductor equipment, this type of function can be useful when pulsed electrical signals must be monitored or coordinated with other system events. The Sync Out designation further indicates that the assembly provides a synchronization-related output as part of its intended operation.

Therefore, the 810-048219-015 should not be treated as a generic PCB. It is a specialized board designed to perform a defined function within the larger Lam Research equipment architecture.

Signal Coordination

The combination of Pulse Sample & Hold and Sync Out suggests that timing and signal coordination are important aspects of this assembly.

In automated semiconductor equipment, different electronic and mechanical operations often need to occur in a controlled sequence. A synchronization output can help coordinate related control events, while sample-and-hold circuitry can preserve a captured signal condition for further processing.

As a result, an abnormal board condition may potentially affect signal acquisition or timing-related functions. Proper troubleshooting should therefore consider the board together with its connected sensors, signal paths, and control modules.

Board Construction and Inspection

The 810-048219-015 is a populated printed circuit board assembly rather than a simple passive circuit board. When inspecting a used or refurbished unit, technicians should examine the complete assembly before installation.

Important inspection points include:

• PCB surface condition
• Connectors and cable interfaces
• Component discoloration
• Signs of overheating
• Damaged or cracked components
• Loose hardware
• Contamination or corrosion
• Part-number label
• Hardware revision

Because semiconductor equipment operates under demanding production conditions, contamination and long-term thermal or electrical stress should be considered when evaluating an older board.

Typical Maintenance Applications

The Lam Research 810-048219-015 can be useful as a replacement or maintenance spare for compatible semiconductor manufacturing equipment.

Typical applications include:

• Semiconductor process equipment
• Pulse signal monitoring
• Electronic sample-and-hold circuits
• Synchronization control
• Equipment troubleshooting
• Preventive maintenance
• System refurbishment
• Replacement of defective PCB assemblies

The exact equipment platform should be verified before installation because Lam Research systems can use different board revisions and configurations.

Replacement Considerations

When sourcing this board, always match the complete 810-048219-015 part number. Revision information should also be checked because current listings document a Rev C version.

Before replacement, technicians should compare the existing board with the replacement unit and verify connector locations, board markings, physical configuration, and revision information.

After installation, the equipment should be brought back online according to the applicable service procedure. Signal acquisition, pulse-related functions, synchronization output, and communication with connected equipment should be checked before normal production resumes.

Reliable Spare-Part Sourcing

For semiconductor equipment maintenance, the correct OEM part number is more important than simply selecting a visually similar PCB. The Lam Research 810-048219-015 has a specific pulse sample-and-hold and synchronization function, so compatibility should be confirmed before installation.

We supply Lam Research 810-048219-015 for semiconductor equipment repair, replacement, maintenance, and refurbishment projects. Please provide the complete part number and board revision when requesting this component so that the correct configuration can be confirmed.
