Lam Research 810-800081-022 810-800082-201 Electronic Components
Lam Research 853-203016-172
Product Overview
Lam Research 810-800081-022 and 810-800082-201 are professional industrial electronic assemblies for semiconductor manufacturing equipment. Built for VME-based control systems in advanced wafer processing devices, they deliver core backplane connection, signal routing and module communication functions.
The 810-800081-022 is a VME Backplane PCB Assembly. It acts as a high-density connection platform to realize signal transmission and power distribution between multiple VME control boards. The 810-800082-201 serves as a VME Breakout Assembly, bridging signal transmission and interface access between internal control circuits and external device wiring.
Combined, the two components ensure stable operation of Lam Research semiconductor process tools and enable convenient modular maintenance. They are widely applied in semiconductor equipment maintenance, part replacement and device refurbishment scenarios that require reliable VME system performance.
Technical Specifications
Lam Research 810-800081-022
|
Parameter
|
Description
|
|---|---|
|
Manufacturer
|
Lam Research
|
|
Part Number
|
810-800081-022
|
|
Product Type
|
VME Backplane PCB Assembly
|
|
Board Category
|
Control System Backplane
|
|
Core Function
|
VME module interconnection and signal distribution
|
|
Application
|
Semiconductor Processing Equipment
|
|
PCB Type
|
Multi-layer Industrial PCB
|
|
Interface Architecture
|
VME Bus System
|
|
Material
|
Industrial PCB substrate
|
|
Installation Location
|
Equipment Control Rack
|
|
Usage
|
Replacement / Maintenance Spare Parts
|
Lam Research 810-800082-201
|
Parameter
|
Description
|
|---|---|
|
Manufacturer
|
Lam Research
|
|
Part Number
|
810-800082-201
|
|
Product Type
|
VME Breakout Assembly
|
|
Main Function
|
Signal breakout and interface conversion
|
|
Application
|
Semiconductor Manufacturing Equipment
|
|
System Architecture
|
VME Control Platform
|
|
Assembly Type
|
Electronic Interface Board
|
|
Installation
|
Lam Research Equipment Controller
|
|
Usage
|
Equipment Repair and Replacement
|
Functional Description
810-800081-022 VME Backplane Functions
This VME Backplane PCB serves as the core interconnection hub of Lam Research control systems. It provides physical and electrical channels for real-time communication between all VME modules in the equipment rack, integrating discrete control boards into a unified operating system.
Core functions:
- Establish stable VME bus communication channels
- Distribute power evenly among all installed modules
- Maintain high-stability signal transmission
- Support modular controller expansion and upgrade
- Connect CPU, I/O and various interface boards
810-800082-201 VME Breakout Assembly Functions
The breakout assembly acts as a transition interface between internal VME control circuits and external equipment wiring. It standardizes signal access and simplifies system wiring for efficient equipment operation and maintenance.
Core functions:
- Realize signal access and centralized distribution
- Simplify complex equipment wiring connections
- Facilitate daily troubleshooting and routine maintenance
- Provide standardized interface points for control signals
Its optimized breakout design enables technicians to quickly diagnose signal faults and replace modules, effectively reducing equipment downtime.
Standard Installation Procedure
- Safely shut down the semiconductor equipment and cut off the power supply
- Remove the old backplane or breakout assembly
- Install the new replacement module in place
- Check and fasten all connectors and mounting points
- Power on the device and complete system diagnostic tests
Daily Maintenance Recommendations
- Regularly inspect connectors for oxidation and mechanical damage
- Keep the control cabinet clean and dry
- Implement standard ESD protection during component handling
- Real-time monitor equipment communication alarm data
- Store spare boards in professional anti-static packaging
Standard maintenance effectively improves equipment operation stability and reduces unexpected production shutdowns.
Product Advantages
- Customized for Lam Research original semiconductor equipment
- Fully compatible with mainstream VME control architectures
- Stable signal communication and precise signal distribution capability
- Modular plug-and-play replacement solution, easy to operate
- Ideal for legacy semiconductor equipment maintenance and upgrade
- Significantly improves control system stability and production efficiency
- Effectively reduce equipment failure rate and production downtime
- Suitable for enterprise spare parts inventory management
Industrial Supply Support
We provide genuine Lam Research 810-800081-022 VME Backplane PCB Assemblies and 810-800082-201 VME Breakout Assemblies. We also offer a full range of semiconductor equipment spare parts, including control boards, CPU modules, I/O boards, power assemblies, interface cards and other electronic control components for industrial semiconductor production and maintenance.
————————————————————————————————————-
If you would like to learn more about our products and services, please feel free to contact us at any time!
